Connect the DC Output Cable

8
9
Tin wires (7x)
! WARNING:
— Careful! Use correct polarity!
— The DC Load's wire cross section must be 1.5 mm2 (pin 1 & 2)
— Relay contacts shown with de-energized coil (Alarm condition)
— The Earth terminal in the output panel mount connector is not
connected inside the module
DC Output
Cable
T7
CW
For torque reference T5-T7, read
Quick Installation Guide • Chameleon 48V, 650W, HE, IP65, Stand-alone Module
DC Output
Cable
12 11
T6
CW
15
13
14
"Tools & Torque Recommendations" on page 3
Electrical Installation
4
7
5
6
DC Output
Cable
CAN L
5
AL-C
6
AL-NO
10
Connect
DC Output cable
Max 0.4 1.5mm (22 16 AWG)
Cable
Connector,
CCW
male
2
F (Part 343667)
CCW
4
3
CAN H
DC Load
Output Terminals
2
1
−48V
+0V
16
T5
17 CW
Cable
Connector,
male
F (Part 343667)
DC Output
Cable
3
1
