Install the Z8051 OCD Software and
Documentation
The Z8051 On-Chip Debugger (OCD) interface is the interface by which your PC will
communicate with the Z51F3221 MCU to download and execute code. In addition to the
OCD, software such as development tools and sample applications will be installed.

Supported Operating Systems

The Software and Documentation for this reference design supports Microsoft Windows 7
(32-bit/64-bit), Windows Vista (32-bit/64-bit) and Windows XP.
Note: If you have already downloaded the Z8051 software and documentation from the Zilog
Store and installed it following the procedure on the paper insert in your kit (FL0149), skip
this section and proceed to the Z8051 OCD Driver Installation section, below.
Observe the following procedure to install the Z8051 On-Chip Debugger software and
documentation on your computer.
1. Ensure that the OCD interface hardware is not connected to your PC.
2. In a web browser, download the Z8051 Software and Documentation v2.1 or later
from the
drive and double-click to launch the installation file named
3. From the main menu, select
lowing options:
–
–
–
–
Note:
In this filename,
and Documentation release. For example, this version number may be
UM025801-1112
Zilog Store. When the download is complete, unzip the file to your hard
If you do not plan to use the Keil µVision4 IDE, select
SDCC .
If you will be using the Keil µVision4 IDE, select
µVision4 IDE Debugging Support
If you only plan to use the programming features and do not plan to perform any
development, select Zilog OCD
To install all files, select
<version_number>
Go to the installation page
.
.
.
All of the above
refers to the version number of the OCD Software

Install the Z8051 OCD Software and Documentation

Z51F3221 Development Kit
User Manual
Z8051_<version>.exe
, then select one of the fol-
Zilog OCD + Samples +
Zilog OCD + Samples + Keil
.
2.1
7
.
