Note:
The following buttons in the Keil µVision IDE are not supported by the Zilog OCD driver:
To learn more about the full functionality of the Keil µVision IDE, please refer to the Keil
µVision4 IDE documentation.
14. From the
board to run the demo project. As a result, LEDs D2, D3 and D4 will blink in
sequence and the LCD panel will display
Development Kit
15. To stop code execution, select
16. To stop your debugging session, click the
Note:
Refer to
Using the Keil µVision IDE.
HyperTerminal Configuration
A communications program such as HyperTerminal can be used on Windows XP systems
to view the messages from the Z51F3221 Development Board. The following procedure
examines how to configure HyperTerminal for the Z51F3221 demo project.
Note:
The HyperTerminal application is not available in Windows Vista and Windows 7 systems.
If you are using either of these operating systems, consider using/installing different com-
munication software, such as Tera Term. Please refer to the documentation for the particu-
lar emulation software you use to configure it for communication with the Z51F3221
Development Board.
1. In HyperTerminal, select the COM port assigned to the USB-to-UART interface cable
that is connected to the P1 connector on the Development Board.
UM025801-1112
menu, select
Debug
on the Z51F3221 Development Board's LCD panel.
Appendix D
on page 46 for a discussion of Stand-Alone Flash Programming
, or simply press the
Run
Welcome to Zilog's Z51F3221
from the
menu.
Stop
Debug
Start/Stop Debug Session
Z51F3221 Development Kit
User Manual
key on your Windows key-
F5
icon.
HyperTerminal Configuration
33
