In this instance, power to the Board will be terminated, and the USB port of the PC will be
protected from shorting.
Schematic diagrams of the Z51F3221 Development Board are presented
on pages 38 and
39
of this document.
The physical dimensions of the Board are 4.01" x 2.50" (101.8 mm x 63.5 mm).
