Install the Z8051 OCD Software and

Documentation

The Z8051 On-Chip Debugger (OCD) interface is the interface by which your PC will

communicate with the Z51F3220 MCU to download and execute code. In addition to the

OCD, software such as development tools and sample applications will be installed.

Note:

If you have already installed the Z8051 software and documentation from the CD-ROM

following the procedure on the paper insert in your kit (FL0139), skip this section and pro-

ceed to the Z8051 OCD Driver Installation section, below.

Observe the following procedure to install the Z8051 On-Chip Debugger software and

documentation on your computer.

1. Ensure that the OCD interface hardware is not connected to your PC.

2. Insert the Z8051 Software and Documentation CD into your computer's CD-ROM

drive. The setup program launches automatically. If the setup program does not launch

automatically, open Windows Explorer, browse to your CD-ROM drive, and double-

click the file labeled

Note:

In this filename,

and Documentation release. For example, this version number may be

3. Follow the on-screen instructions to complete the OCD software installation.

Z8051 OCD Driver Installation

The driver programs for the Z8051 On-Chip Debugger are copied during the software and

documentation installation. In the following procedure for PCs running the Windows 7 32-

and 64-bit operating systems, ensure that the target side of the OCD will remain uncon-

nected while you install these drivers.

Note:

If you are running Windows Vista, see

ers. If you are running Windows XP, see

UM024303-0312

Z8051_<version_number>.exe

refers to the version number of the OCD Software

<version_number>

Appendix A
