- Page 1 Adam Equipment Cruiser Count (CCT) SERIES Software rev: V 1.00 & above Adam Equipment 2018 ©...
- Page 2 Easy Reference: Model name of the scale: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place: Adam Equipment 2018 ©...
-
Page 3: Table Of Contents
CONTENTS P.N. 3.02.6.6.14037, Revision D3, November 2018 1.0 INTRODUCTION .............................. 4 2.0 SPECIFICATIONS ............................5 2.1 COMMON SPECIFICATIONS ........................7 3.0 INSTALLATION..............................8 3.1 LOCATING THE SCALE ..........................8 3.2 INSTALLATION OF CCT SCALES ......................9 4.0 KEY DESCRIPTIONS ............................. 10 5.0 DISPLAYS ............................... -
Page 4: Introduction
1.0 INTRODUCTION • The Cruiser Count (CCT) series provides accurate, fast and versatile counting scales. • There are 3 types of scale within the CCT series: CCT: Standard models CCT-M: Trade approved models CCT-UH: High resolution models • Cruiser counting scales can weigh in pound, gram and kilogram weighing units. -
Page 5: Specifications
2.0 SPECIFICATIONS CCT SERIES Model # CCT 4 CCT 8 CCT 16 CCT 32 CCT 48 Maximum 4000 g 8000 g 16kg 32 kg 48 kg Capacity Readability 0.1 g 0.2 g 0.0005 kg 0.001 kg 0.002 kg Tare Range... - Page 6 Model: CCT 40M UNITS OF MAXIMUM TARE READABILITY REPEATIBILITY LINEARITY MEASURE CAPACITY RANGE Kilograms 40 kg - 40 kg 0.01 kg 0.01 kg 0.004 kg Pounds 88 lb - 88 lb 0.02 lb 0.02 lb 0.01 lb CCT-UH SERIES Model: CCT 8UH UNITS OF MAXIMUM TARE...
-
Page 7: Common Specifications
COMMON SPECIFICATIONS Stabilisation 2 Seconds typical Time Operating -10°C - 40°C Temperature 14°F - 104°F Power supply 230 VAC 50/60 Hz 120 VAC available Battery Internal rechargeable battery (~90 hours operation) Calibration Automatic External Display 3 x 6 digits LCD digital displays Balance ABS Plastic, Stainless Steel platform Housing... -
Page 8: Installation
3.0 INSTALLATION LOCATING THE SCALE The scales should not be placed in a location that will • reduce the accuracy. Avoid extremes of temperature. Do not place in direct • sunlight or near air conditioning vents. • Avoid unsuitable tables. The table or floor must be rigid and not vibrate. -
Page 9: Installation Of Cct Scales
INSTALLATION OF CCT SCALES • The CCT Series come with a stainless steel platform packed separately. • Place the platform in the locating holes on the top cover. • Do not press with excessive force as this could damage the load cell inside. -
Page 10: Key Descriptions
4.0 KEY DESCRIPTIONS Keys Functions [0-9] Numeric entry keys, used to manually enter a value for tare weights, unit weight, and sample size. [CE] Used to clear the unit weight or an erroneous entry. Add the current count to the accumulator. Up to 99 values or full capacity [Print M+] of the weight display can be added. -
Page 11: Displays
5.0 DISPLAYS The scales have three digital display windows. These are “Weight”, “Unit Weight” and “Count pcs”. It has 6-digit display to indicate the weight on the scale. Arrows above symbols will indicate the following: Charge State Indicator, as above Net Weight Display, "Net"... -
Page 12: Unit Weight Display
UNIT WEIGHT DISPLAY • This display will show the unit weight of a sample. This value is either input by the user or computed by the scale. The unit of measurement may be set to grams or pounds depending on region. •... -
Page 13: Operation
6.0 OPERATION SETTING THE WEIGHING UNIT: lb or kg The scale will turn on displaying the last weighing unit selected, either kilograms or pounds. To change the weighing unit press the [Units] key. To change the weighing unit press the [SETUP] key and use the [1] or [6] keys to scroll through the menu until ‘units’... -
Page 14: Taring
TARING • Zero the scale by pressing the [0] key if necessary. The indicator “0” will be • Place a container on the platform and its weight will be displayed. • Press [Tare] to tare the scale. The weight that was displayed is stored as the tare value which is subtracted from the display, leaving zero on the display. -
Page 15: Setting Unit Weight
6.3.1 Setting Unit Weight In order to do parts counting it is necessary to know the average weight of the items to be counted. This can be done by weighing a known number of the items and letting the scale determine the average unit weight or by manually inputting a known unit weight using the keypad. -
Page 16: Counting More Parts
6.3.2 Counting more parts • After the unit weight has been determined or entered, it is possible to use the scale for parts counting. The scale can be tared to account for the container weight mentioned in section 6.2. • After the scale is tared the items to be counted are added and the "Count"... -
Page 17: Manually Accumulated Totals
• Once the “Lo” value is set, you will be prompted to set the “Hi” value, confirm this by following the same procedure as for the “Lo” value. • Placing an object on the scale will now bring up an arrow indicator pointing to “Lo, Mid or Hi”... -
Page 18: Automatic Accumulated Totals
6.3.6 Automatic Accumulated Totals • The scale can be set to automatically accumulate totals when a weight is placed on the scale. This eliminates the need to press the [M+] key to store values into the memory. However the [M+] key is still active and can be pressed to store the values immediately. -
Page 19: Rs-232 Interface
8.0 RS-232 INTERFACE The CCT Series are supplied with a USB and RS-232 bi-directional interface. The scale when connected to a printer or computer through the RS-232 interface, outputs the weight, unit weight and count. - Page 20 Data Format-Normal Output: Date 12/09/2006 Time 14:56:27 Scale ID User ID Net Wt. 0.100kg Tare Wt. 0.000kg Gross Wt 0.100kg Total Wt. 0.100kg Unit Wt. 3.04670g Pieces 10 pcs <lf><cr> Includes 2 line feeds with carriage return <lf><cr> Data Format with Accumulation On: Date 7/06/2018 Time...
- Page 21 Data Format with Accumulation Off, with Hi/Lo set: Date 7/06/2018 Time 14:56:27 Scale ID User ID Net Wt. 0.97kg Tare Wt. 0.000kg Gross Wt 0.97kg Unit Wt. 3.04670g Pieces 32 pcs High Limit 50PCS Low Limit 20PCS Accept Date 7/06/2018 Time 14:56:27 Scale ID...
- Page 22 Data Format Print 1 Copy, Accumulation Off: Date 08/6/2018 Time 12:17:24 Scale.ID xxxx User ID xxxx Net Wt. 0.054kg Tare Wt. 0.000kg Gross Wt. 0.054kg Unit Wt. 3.04670g Pieces 18PCS PC – ST, GS, 0.052kg, ST,GS,- 0.014kg,- ST,GS,- 0.013kg,- ST,GS,- 0.013kg,- ST,GS,- 0.013kg,-...
-
Page 23: Input Commands Format
Prints the results to a PC or printer using the RS-232 interface. It also adds the value to the accumulation memory if the accumulation function is not set to automatic. In CCT series, the [Print] key will either print the current items being counted or the results of the accumulation memory if [M+] is pressed first. -
Page 24: Usb Setup
4800: For setting the baud rate. English: For setting the language. AC off: Selecting the option of accumulating manually or turned off. Manual: Selecting by output, e.g. manual. ATP: Printer type. Copy 1: Number of outputs. Available options when selecting the ‘PC’ option (use the [Tare] key to select). 4800: For setting the baud rate. -
Page 25: Clock, Sleep, Auto Off Functions
9.0 CLOCK, SLEEP, AUTO OFF FUNCTIONS 9.1 REAL TIME CLOCK SETUP The Real Time Clock (RTC) is used only for the RS-232 output. The Date and Time can be set as required. The scale will keep the clock running even when the power is off. Setting up the clock •... -
Page 26: Auto Sleep Function
9.2 AUTO SLEEP FUNCTION This function may be enabled or disabled by the user. If enabled, when the scale is not used for some time (as pre-set by the user under this function) it automatically switches off. To set this parameter: ... -
Page 27: Battery
9.4 BATTERY • The scales can be operated from the battery, if desired. The battery life is approximately 90 hours. • The charge state indicator displays three stages. • To charge the battery, simply plug the scale into the mains and switch the mains power ON. -
Page 28: Error Codes
10.0 ERROR CODES During the initial power-on testing or during operation, the scale may show an error message. The meaning of the error messages is described below. If an error message is shown, repeat the step that caused the message, turning the balance on, carry out the calibration or other functions. -
Page 29: Replacement Parts And Accessories
11.0 REPLACEMENT PARTS AND ACCESSORIES If you need to order any spare parts and accessories, contact your supplier or Adam Equipment. A partial list of such items is as follows: Mains power cord Replacement Battery Stainless Steel Pan ... -
Page 30: Warranty Information
WARRANTY INFORMATION Adam Equipment offers Limited Warranty (Parts and Labour) for the components failed due to defects in materials or workmanship. Warranty starts from the date of delivery. During the warranty period, should any repairs be necessary, the purchaser must inform its supplier or Adam Equipment Company. - Page 31 State of California to cause cancer and birth defects or other reproductive harm. Adam Equipment products have been tested with, and are always supplied with mains power adaptors which meet all legal requirements for the intended country or region of operation, including electrical safety, interference and energy efficiency.
- Page 32 Private Industrial Park Kempton Park, Bibra Lake Zhuanyang Avenue Johannesburg, Perth Wuhan Economic & Technological Republic of South Africa WA 6163 Development Zone Western Australia 430056 Wuhan Phone: +61 (0) 8 6461 6236 P.R.China Phone +27 (0)11 974 9745 Fax +61 (0) 8 9456 4462 Phone: + 86 (27) 59420391 Fax: +27 (0)11 392 2587 e‐mail: Fax + 86 (27) 59420388 e‐mail: e‐mail: sales@adamequipment.com.au sales@adamequipment.co.za info@adamequipment.com.cn © Copyright by Adam Equipment Co. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice. All information contained within this publication is to the best of our knowledge timely, complete and accurate when issued. However, we are not responsible for misinterpretations which may result from the reading of this material. The latest version of this publication can be found on our Website. www.adamequipment.com © Adam Equipment Company 2018...
