- Page 1 Adam Equipment Cruiser Count (CCT) SERIES Software rev: V 1.00 & above © Adam Equipment Company 2020...
- Page 2 Easy Reference: Model name of the scale: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place: © Adam Equipment Company 2020 ...
-
Page 3: Table Of Contents
9.3 C-Con ..........................16 9.4 Dot ............................. 16 9.5 M-Tare ..........................16 9.6 G1 and G2 ........................17 9.7 Filter ..........................17 9.8 P-Zero ..........................17 9.9 K-zero ..........................17 9.10 Auto/ zero tracking ......................18 © Adam Equipment Company 2020... - Page 4 9.11 Capacity ........................18 9.12 Count Unit ....................... 18 9.13 Dual ......................... 18 9.14 Linear calibration ...................... 18 10.0 SERVICE INFORMATION ....................19 WARRANTY INFORMATION ..................... 20 © Adam Equipment Company 2020 ...
-
Page 5: Introduction
• The scales include automatic zero tracking, audible alarm for pre-set counts, automatic tare, pre-set tare, an accumulation facility that allows the count to be stored and recalled as an accumulated total. © Adam Equipment Company 2020... -
Page 6: Specifications
0.033 lb Model: CCT 40M UNITS OF MAXIMUM TARE READABILITY REPEATIBILITY LINEARITY MEASURE CAPACITY RANGE Kilograms 40 kg -40 kg 10 g 30 g Pounds 88 lb -88 lb 0.022 lb 0.044lb 0.066 lb © Adam Equipment Company 2020 ... -
Page 7: Model: Cct 8Uh
0.0044 lb 0.0009 lb 0.0026 lb Model: CCT 48UH UNITS OF MAXIMUM TARE READABILITY REPEATIBILITY LINEARITY MEASURE CAPACITY RANGE Grams 48 kg -48 kg 0.5 g Pounds 100lb -100 lb 0.0011 lb 0.0022 lb 0.0066 lb © Adam Equipment Company 2020... -
Page 8: Common Specifications
Parts counting, checkweighing, accumulating memory, pre-set count with alarm Interface RS-232 bi-directional interface English, German, French, Spanish selectable text Date/Time Real Time Clock (RTC), To print date and time information (Dates in year/month/day, day/month/year or month/day/year formats- Battery backed) © Adam Equipment Company 2020 ... -
Page 9: Installation
Avoid air movement such as from fans or opening doors. • Do not place near open windows or air conditioning vents. Keep the scales clean. Do not stack material on the scales • when they are not in use. © Adam Equipment Company 2020... -
Page 10: Installation Of Cct Scales
The scale can be opened by unscrewing the 5 designated points located beneath the scale: 2 next to the battery 2 at the front of the scale 1 in the centre next to the recharge board. © Adam Equipment Company 2020 ... -
Page 11: Scale Components
3 – Display 4 – Spirit level 5 – Load cell metal frame (upper supporter) 6 – Load cell 7 – Load cell metal frame (lower supporter) 8 – Power cable 9 – Battery to Display cable © Adam Equipment Company 2020... -
Page 12: Replacing The Load Cell
Screw in the 2 central screw points to hold the load cell in place, then carefully screw in the 4 exterior screw points. Once secure, place the scale’s exterior casing back onto the scale base and screw to close. © Adam Equipment Company 2020 ... -
Page 13: Replacing The Display
To replace the PCB, ensure that you have switched off the power, then follow these steps: Unscrew the plastic cover for the charging board and USB components located beneath the scale Remove the USB and charging component © Adam Equipment Company 2020... -
Page 14: Calibration/ Linearity Settings
↵ Before configuration is completed, hold down the [Tare] key to bring up the user information screen with username and password. Entering the correct password will bring you to the setup menu. © Adam Equipment Company 2020 ... -
Page 15: Factory Parameters
For user calibration, please follow the instructions outlined in the calibration section of the manual. The factory menu comprises of a wider variety of settings and options such as language, currency, decimal and linear calibration settings. © Adam Equipment Company 2020... -
Page 16: A/D Count
To enter this parameter, press the [Tare] ↵ key when “C-Con” is shown. Use the numeric [1] or [6] keys to alternate between “dot” and “comma” options and [Tare] ↵ to select. M-Tare This option allows you to set the tare limit. © Adam Equipment Company 2020 ... -
Page 17: G1 And G2
To enter this parameter, press the [Tare] ↵ key when “k-zero” is shown. Use the numeric [1] or [6] keys to alternate between the options and press [Tare] ↵ to select. Note: Trade approved machines require this to be set in accordance with specific rules. © Adam Equipment Company 2020... -
Page 18: Auto/ Zero Tracking
To enter this parameter, press the [Tare] ↵ key when “Dual” is shown. Use the numeric [1] or [6] keys to alternate between the options and press [Tare] ↵ to select. 9.14 Linear calibration For information about the linear calibration procedure, please see section 7. © Adam Equipment Company 2020 ... -
Page 19: Service Information
Include any recent history of the unit. For example: -Has it been working since it’s delivered -Has it been in contact with water -Damaged from a fire -Electrical Storms in the area -Dropped on the floor, etc. © Adam Equipment Company 2020... -
Page 20: Warranty Information
During the warranty period, should any repairs be necessary, the purchaser must inform its supplier or Adam Equipment Company. The company or its authorised Technician reserves the right to repair or replace the components at any of its workshops depending on the severity of the problems. However, any freight involved in sending the faulty units or parts to the service centre should be borne by the purchaser. - Page 21 WEEE 2012/19/EU This device may not be disposed of in domestic waste. This also applies to countries outside the EU, per their specific requirements. Disposal of batteries (if fitted) must conform to local laws and restrictions. Cet appareil ne peut être éliminé avec les déchets ménagers. L’élimination de la batterie doit être effectuée conformément aux lois et restrictions locales. Dieses Gerät nicht mit dem Hausmüll entsorgt. Dispositivo no puede ser desechado junto con los residuos domésticos Dispositivo non può essere smaltito nei rifiuti domestici. FCC / IC CLASS A DIGITAL DEVICE EMC VERIFICATION STATEMENT NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules and Canadian ICES‐003/NMB‐003 regulation. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. CALIFORNIA PROPOSITION 65 ‐ MANDATORY STATEMENT WARNING: This product includes a sealed lead‐acid battery which contains chemicals known to the State of ...
- Page 22 ADAM EQUIPMENT is an ISO 9001:2015 certified global company with more than 40 years’ experience in the production and sale of electronic weighing equipment. Adam products are predominantly designed for the Laboratory, Educational, Health and Fitness, Retail and Industrial Segments. The product range can be described as follows: ‐Analytical and Precision Laboratory Balances ‐Compact and Portable Balances ‐High Capacity Balances ‐Moisture analysers / balances ‐Mechanical Scales ‐Counting Scales ‐Digital Weighing/Check‐weighing Scales ‐High performance Platform Scales ‐Crane scales ‐Mechanical and Digital Electronic Health and Fitness Scales ‐Retail Scales for Price computing For a complete listing of all Adam products visit our website at www.adamequipment.com Adam Equipment Co. Ltd. Adam Equipment Inc. AE Adam GmbH. Maidstone Road, Kingston 1, Fox Hollow Rd., Instenkamp 4 Milton Keynes Oxford, CT D‐24242 Felde 06478 MK10 0BD USA UK Germany Phone: +1 203 790 4774 Phone:+44 (0)1908 274545 Phone +49 (0)4340 40300 0 Fax: +1 203 792 3406 e‐ Fax: +44 (0)1908 641339 e‐mail: Fax: +49 (0)4340 40300 20 e‐ mail: ...
