3. Navigate to the Multicast Configuration page of the SPA's web interface.
4. Check the box to Enable Multicast operation at the top of the page.
5. Enter the multicast IP address and port numbers used by the V3.1 Paging Server
and/or Polycom IP phones into the multicast IP address and port number fields for the
desired priority groups on the SPA's Multicast Configuration page. See
When configuring the Polycom Paging group, we will use the odd-numbered port
although the SPA supports both even-numbered and odd-numbered ports.
SPA Paging Group
Priority 9
Priority 8
Priority 7
5. If you are configuring the SPA to join Polycom Paging groups, select the desired
channel/group numbers at the bottom of the Multicast Configuration page.
Each of the three Polycom channel/group menus can be individually disabled or set to
channel/group numbers 1 through 25. See
6. Save and Reboot to store changes.
RING CENTRAL CONFIGURATION GUIDE: SIP PAGING ADAPTER (SPA)
Table 8-1. Example SPA Paging Groups
Address
234.2.1.1
224.0.1.116
239.168.3.8
CyberData Corporation
3 Justin Court, Monterey, CA 93940
www.cyberdata.net
P 831.373.2601 | F 831.373.4193
Doc. 931050B
Port
2000
5001
9000
Figure 8-4.
