Network settings

Accessing the camera through a network requires that you define certain network
settings. Use the "Network" folder to define the network settings. See Figure 4 below for
further information.
Figure 4: Network window (TCP/IP tab shown)
Parameters
1. TCP/IP
TruVision IP Compact PTZ Camera Configuration Manual
Description
NIC Type: Specifies the NIC type. Default is Auto. Other options include: 10M
Half-dup, 10M Full-dup, 100M Half-dup and 100M Full-dup.
DHCP: Enable to automatically obtain an IP address and other network
settings from that server.
IPv4 Address: Specifies the IPv4 address of the camera.
IPv4 Subnet Mask: Specifies the IPv4 subnet mask.
IPv4 Default Gateway: Specifies the IPv4 gateway IP address.
IPv6 Mode: Specifies the IPv6 mode, including Manual, DHCP and Router
Advertisement.
IPv6 Address: Specifies the IPv6 address of the camera.
IPv6 Subnet Mask: Specifies the IPv6 subnet mask.
IPv6 Default Gateway: Specifies the IPv6 gateway IP address.
Mac Address: Specifies the MAC address of the camera.
MTU: Specifies the valid value range of MTU. Default is 1500.
Multicast Address: Specifies a D-class IP address between 224.0.0.0 to
239.255.255.255. Only specify this option if you are using the multicast
function. Some routers prohibit the use of multicast function in case of a
network storm.
