- Page 1 TruVision Stainless Steel PTZ Camera Installation Guide P/N 1073420-EN • REV A • ISS 30JAN18...
- Page 3 © 2018 United Technologies Corporation, Copyright Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks Trade names used in this document may be trademarks or and patents registered trademarks of the manufacturers or vendors of the respective products.
- Page 4 For more information on warranty disclaimers and product safety information, please check www.firesecurityproducts.com/policy/product-warning/ or scan the following code: Contact For contact information go to: www.interlogix.com or information www.firesecurityproducts.com and manuals To get translations for this and other product manuals go to:...
-
Page 5: Table Of Contents
SD memory card installation 11 Mounting the PTZ dome camera 12 Mounting the junction box 13 Using the camera with an Interlogix NVR or Hybrid DVR or another system 15 Using the camera with TruVision Navigator 16 Access the camera over the internet 16... -
Page 6: Introduction
Introduction Product overview This is the installation guide for the TruVision Stainless Steel PTZ dome camera model: • TVP-5201 (2MPX wall-mount PTZ dome camera, 23X) Installation This section provides information on how to install the cameras. Installation environment When installing your product, consider these factors: •... -
Page 7: Package Contents
service person for servicing. Moisture can damage the camera and also create the danger of electric shock. Servicing: Do not attempt to service this camera • yourself. Any attempt to dismantle or remove the covers from this product will invalidate the warranty and may also result in serious injury. - Page 8 CD with configuration manual Equipment disposal sheet and TruVision Device Manager Battery disposal sheet Hex wrench Junction box Screw A (10 pcs.) 1.6 mm (0.06 in.) 5.0 mm 10.7 mm (0.42 in.) (0.20 in.) 5.5 mm (0.22 in.) 5.85 mm (0.23 in.) 13.6 mm (0.54 in.)
- Page 9 White sealing plug (3 pcs) Black sealing plug (3 pcs) 6 mm (0.24 in.) 6 mm (0.24 in.) 23.5 mm 23.5 mm (0.93 in.) (0.93 in.) Drill template – junction box 328 mm (12.91 in.) CAUTION: Use direct plug-in UL listed power supplies marked Class 2/CE certified or LPS (limited power source) of the required output rating as listed on the unit.
-
Page 10: Camera Description
Camera description Figure 1: PTZ camera description and connectors 1200 mm (47.24 in.) ⑦ 250 mm (9.84 in.) ① ② ③ ④ ⑤ ⑥ 1. 24V power supply (red 24 VAC, 4. Alarm inputs (green, blue, yellow_green ground, black 24 purple, gray, white, VAC) black_white, brown_white) /... -
Page 11: Alarm Input And Output Connections
Alarm input and output connections The alarm output can be used to turn on and off an external alarm device. Connect a 30 VDC/1A external power supply to the alarm output. If using an AC power supply, an external relay must be used to prevent electric shock and damage to the device. -
Page 12: Mounting The Ptz Dome Camera
① ② ④ ③ Note: Remove the thin foam shipping ring prior to completing the installation. Optional: Insert the memory card into the SD card slot (1) until it clicks into place. Reinstall the bubble assembly on the camera housing. Mounting the PTZ dome camera The TruVision Stainless Steel PTZ Wall Bracket (TVP-WBS, not included) is required to wall-mount the PTZ camera, and... -
Page 13: Mounting The Junction Box
Refer to the installation guides provided with the TVP-WBS and TVP-PAS mounting kits for instructions on mounting the stainless steel PTZ camera to the wall or ceiling. After completing the PTZ camera installation, you can remove the safety lanyard handle. See the image below. Mounting the junction box To mount the PTZ camera junction box: Drill mounting holes in the mounting surface according to... - Page 14 Route the camera cable harness through the cable access hole on the junction box and tighten the waterproof nut. Note: Insert the PoE cable or BNC cable first, followed by the RS-485 wires, audio input and output wires, alarm input and output wires, and power supply wires. For the power supply wires, the red plastic interface must first be removed.
-
Page 15: Using The Camera With An Interlogix Nvr Or Hybrid Dvr Or Another System
Connect the wires inside the junction box and attach the cover of the junction box with the screw As. Using the camera with an Interlogix NVR or Hybrid DVR or another system Please refer to the NVR/DVR user manuals for instructions on connecting and operating the camera with these systems. -
Page 16: Using The Camera With Truvision Navigator
Using the camera with TruVision Navigator The camera can be connected to an Interlogix NVR, hybrid DVR, or directly to TruVision Navigator. Please refer to the user manual of TruVision Navigator and/or of the NVR or hybrid DVR for instructions. - Page 17 Note: • The default IP address of the camera is 192.168.1.70. • For the camera to enable DHCP by default, you must activate the camera via TruVision Device Manager. Please refer to the following section, “To activate the camera via TruVision Device Manager.” Type the password in the Password field.
- Page 18 Figure 3: Example of a configuration window To activate the camera via TruVision Device Manager: For instructions on how to activate the camera using TruVision Device Manager, refer to the TruVision Device Manager User Manual. Go to www.interlogix.com/video/product/truvision- device-manager and click Downloads. Installation Guide...
-
Page 19: Specifications
Specifications PTZ camera Electrical Voltage input 24 VAC, Hi-PoE Power consumption Max. 60 W Miscellaneous Connectors 24 VAC, Alarm In/Out, RS-485, Ethernet RJ45 connector, Audio in/output, CVBS (960H) Output Operating temperature -40 to +65°C (-40 to +149°F) Dimensions 262 × 330 mm (10.3 × 13.0 in.) Weight 10 kg (22 lb.) Environmental rating... -
Page 20: Pin Definitions
Pin definitions There are eight wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color of straight and crossover cable connection: Figure 4: Straight-through cable White/Orange White/Orange Orange Orange White-Green White-Green Blue Blue White/Blue...
