TruVision HD-TVI 1080P
Wedge Camera
Configuration Manual
P/N 1073184-EN • REV A • ISS 23JUN16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TruVision TVW-2401 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Interlogix TruVision TVW-2401

  • Page 1 TruVision HD-TVI 1080P Wedge Camera Configuration Manual P/N 1073184-EN • REV A • ISS 23JUN16...
  • Page 2 Copyright © 2016 United Technologies Corporation. All rights reserved. Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. Trademarks and The TruVision and Interlogix names and logos are trademarks of patents United Technologies. Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.
  • Page 3 Content Introduction 2 HD-TVI 1080P Wedge Cameras 2 Programming 2 Call up the camera OSD menu 2 Menu tree 3 Configuration 3 Format 3 Languages 3 Main Menu 4 AE (Auto Exposure) 4 WB (White Balance) 4 Day/Night 5 Video Setting 6 Reset 6 Save &...
  • Page 4 Introduction This is the configuration manual for following camera models: HD-TVI 1080P Wedge Cameras  TVW-2401 (1080P TVI Wedge Camera, Fixed Lens, IR, PAL)  TVW-4401 (1080P TVI Wedge Camera, Fixed Lens, IR, NTSC) Programming Once the camera has been installed, the camera can be configured using the built-in OSD (On Screen Display) button or the menu of a TVI DVR .
  • Page 5 Note: You cannot exit the camera setup menu using the Menu button on the camera. Menu tree The menu tree for the TruVision 1080P TVI wedge camera is shown below. Configuration This section describes how to set up the menu settings. Format Select PAL or NTSC.
  • Page 6 Main Menu AE (Auto Exposure) AE describes the brightness-related parameters. You can adjust the image brightness by using BRIGHTNESS, EXPOSURE MODE, and GAIN in different light conditions. Select the following options under the AE menu: BRIGHTNESS Brightness refers to the brightness of the image. You can set the brightness value from 1 to 10 to darken or brighten the image.
  • Page 7 In ATW mode, white balance is being adjusted automatically according to the color temperature of the scene illumination. You can set the R GAIN/B GAIN value from 0 to 255 to adjust the shades of red/blue color of the image. Day/Night You can select Color, B/W, and SMART...
  • Page 8 Video Setting Move the cursor to VIDEO SETTING and press the confirm button to enter the submenu. CONTRAST, SHARPNESS, COLOR GAIN, MIRROR adjustable. Select the following options under the video setting menu: CONTRAST This feature enhances the difference in color and light between parts of an image.
