TruVision IP Compact PTZ
Camera Configuration
Manual
P/N 1073407-EN • REV B • ISS 23MAY18

Advertisement

Table of Contents
loading

Related Manuals for Interlogix TVP-5101

Summary of Contents for Interlogix TVP-5101

  • Page 1 TruVision IP Compact PTZ Camera Configuration Manual P/N 1073407-EN • REV B • ISS 23MAY18...
  • Page 2 Copyright © 2018 United Technologies Corporation. Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks and Trade names used in this document may be trademarks or patents registered trademarks of the manufacturers or vendors of the respective products.

  • Page 3: Table Of Contents

    Content Introduction 3 Contact information and manuals /tools /firmware 4 Network connection 5 Checking your web browser security level 5 Activating the camera 6 Overview of the camera web browser 9 Camera configuration 11 Configuration menu overview 11 Local configuration 12 System time 13 Network settings 15 Recording parameters 19...
  • Page 4 Restore default settings 63 Import/export a configuration file 64 Upgrade firmware 64 Reboot camera 64 System service 65 About 65 Camera operation 66 Logging on and off 66 Live view mode 66 Playing back recorded video 66 Snapshots 68 Searching event logs 69 Index 75 TruVision IP Compact PTZ Camera Configuration Manual...

  • Page 5: Introduction

    Introduction This is the configuration manual for the following TruVision IP PTZ camera models:  TVP-5101 (2.0 MPX, 4X, 20 m IR, H.265/H.264)  TVP-5102 (2.0 MPX, 20X, 150 m IR, H.265/H.264)  TVP-5103 (3.0 MPX, 20X, 50 m IR, H.265/H.264) The installation guide and configuration manual are available on our web site.

  • Page 6: Contact Information And Manuals /Tools /Firmware

    Contact information and manuals /tools /firmware For contact information and to download the latest manuals, tools, and firmware, go to the web site of your region. Americas: www.interlogix.com EMEA: www.firesecurityproducts.com Manuals are available in several languages. Australia/New Zealand: www.utcfs.com.au TruVision IP Compact PTZ Camera Configuration Manual...

  • Page 7: Network Connection

    Network connection This manual explains how to configure the camera over the network with a web browser. TruVision IP PTZ cameras can be configured and controlled using Microsoft Internet Explorer (IE) and other browsers. The procedures described use Microsoft Internet Explorer (IE) web browser.

  • Page 8: Activating The Camera

    Under Reset Custom Settings, click the security level for the whole zone in the Reset To box, and select Medium. Click Reset. Then click to the Internet Options Security tab window. 5. Click Apply in the Internet Options Security tab window. Windows users Internet Explorer for Windows operating systems have increased security measures to protect your PC from any malicious software being installed.
  • Page 9 You can activate a password via a web browser and via TruVision Device Manager (included on the CD to find the IP address of the camera). Activation via the web browser: 1. Power on the camera and connect the camera to the network. 2.
  • Page 10 3. Enter the password in the password field, and confirm it. Note: A valid password range must be between 8 and 16 characters. You can use a combination of numbers, lower and upper case letters, and special characters : _ - , .

  • Page 11: Overview Of The Camera Web Browser

    Overview of the camera web browser The camera web browser lets you view, record, and play back recorded videos on the optional SD card as well as manage the camera from any PC with Internet access. The browser’s easy-to-use controls give you quick access to all camera functions. See Figure 1 below.
  • Page 12 Name Description Start/stop Click to record live video. The video will be saved to the recording default folder and the directory of the folder can be set in Local Configuration > Browser Configuration. 3D Zoom Click to enable 3D zoom and draw a rectangle using the left mouse button to specify where you want to zoom in.

  • Page 13: Camera Configuration

    Camera configuration This chapter explains how to configure the cameras through a web browser. Once the camera hardware has been installed, configure the camera’s settings through the web browser. You must have administrator rights in order to configure the cameras over the internet.

  • Page 14: Local Configuration

    Item Description Security Defines who can use the camera, their passwords and access privileges, RTSP authentication, IP address filter, and telnet access. Network Defines the network parameters required to access the camera over the internet. Video/Audio Defines recording parameters. Image Defines the image parameters, OSD settings and text overlay.

  • Page 15: System Time

    Parameters Description 3. Enable Meta Data Overlay It refers to the rules on your local browser. Specify whether or not to display the colored marks when motion detection is triggered. For example, when the rules option is enabled and motion is detected, the moving object will be marked with a green rectangle in live view.
  • Page 16 2. From the Time Zone drop-down menu, select the time zone that is the closest to the camera’s location. 3. NTP: Enable the function and enter the server NTP address to synchronize with an NTP server. The time interval can be set from 1 to 10080 minutes. -Or- Manual Time Sync.: Enable the Manual Time Sync...

  • Page 17: Network Settings

    Network settings Accessing the camera through a network requires that you define certain network settings. Use the “Network” folder to define the network settings. See Figure 4 below for further information. Figure 4: Network window (TCP/IP tab shown) Parameters Description TCP/IP NIC Type: Specifies the NIC type.
  • Page 18 Parameters Description DNS Server: Specifies the DNS server for your network and the alternate DNS server that can be used. Host Name Configuration: Specifies the DNS name the user can define. DDNS Specifies IP server, DynDNS and ezDDNS. PPPoE Use this option when using a direct modem connection between the camera and ISP.
  • Page 19 To define the DDNS parameters: 1. From the menu toolbar, click Camera Configuration > Network > DDNS. 2. Check Enable DDNS to enable this feature. 3. Select DDNS Type. Two options are available: DynDNS and IPServer. • DynDNS: Enter the following information: Domain name: DynDNS web site Server address: members.dyndns.org Host name: URL created in DynDNS...
  • Page 20 To define the 802.1x parameters: Note: The switch or router to which the camera is connected must also support the IEEE 802.1X standard, and a server must be configured. Please apply and register a user name and password for 802.1X in the server. 1.

  • Page 21: Recording Parameters

    Sender’s Address: The email address of the sender. SMTP Server: The SMTP Server IP address or host name. SMTP Port: The SMTP port. The default is 25. Enable SSL: Check the checkbox to enable SSL if it is required by the SMTP server.
  • Page 22 Note: When you add the camera to a recorder, you need to set-up the recording parameters in the recorder. Figure 5: Video & Audio Settings menu (Video tab shown) Parameter Description Stream Type Specifies the streaming method used. Options include: Main Stream (Normal), Substream, and Third Stream. Use main stream for live viewing and recording with high resolutions and bandwidth.
  • Page 23 Parameter Description Frame Rate Specifies the frame rate for the selected resolution. The frame rate is the number of video frames that are shown or sent per second. Note: The maximum frame rate depends on the camera model and selected resolution. Please check the camera specifications in its datasheet.

  • Page 24: Roi Encoding Of An Image

    Figure 7: Display video analytics information menu Description When Dual-VCA mode is enabled, the camera sends video analytics results (metadata) to an NVR or other platforms to generate a VCA alarm. ROI encoding of an image You can select an important area of detail or ROI (Region of interest) in a stream, such as a number plate or face.

  • Page 25: Ptz Parameters

    ROI Level: Choose the image quality enhancing level. Default is 6. Region Name: Enter the desired region name. 5. Using the mouse, draw an area on the image. 6. Enable Face Tracking Target Tracking (4), if required. This is an intelligent analysis feature that facilitates auto-tracking.
  • Page 26 2. Configure the following settings: Basic Settings: Proportional Pan If you enable this function, the pan/tilt speeds change according to the amount of zoom. When there is a large amount of zoom, the pan/tilt speed will be slower for keeping the image from moving too fast on the live view image.
  • Page 27 Auto Scan Speed The camera provides five scan modes: auto scan, tilt scan, frame scan, random scan and panorama scan. The scan speed can be set from level 1 to 40. Max. Tilt Angle You can set the maximum tilt angle of the lens. There are sixteen options: -15 to 90, -14 to 90, -13 to 90, -12 to 90, -11 to 90, -10 to 90, -9 to 90, -8 to 90, -7 to 90, -6 to 90, -5 to 90, -4 to 90, -3 to 90, - 2 to 90, -1 to 90, 0 to 90.
  • Page 28 2. Click the Enable Limit checkbox to enable the limit function. 3. Click the button and use the PTZ control panel to set the limits of the camera movement. You can also call up defined presets and set them as the limits of the camera.
  • Page 29 To define a scheduled task: 1. From the menu toolbar, click Camera Configuration > > Scheduled Tasks. 2. Check the checkbox of Enable Scheduled Task. 3. Choose the task type from the drop-down list. You can choose from one of the following: Preset Tour Tilt Scan...
  • Page 30 5. Click Save to save changes. Park actions This is the action that will run automatically after the dwell time. A park action can be, for example, a scan, preset, preset tour, or a shadow tour. Note: The Scheduled Tasks function (see page 26) has priority over the Park Action function.
  • Page 31 Privacy masks Privacy masks let you conceal sensitive areas (such as neighboring windows) to protect them from view on the monitor screen and in the recorded video. The masking appears as a blank area on screen. You can create up to 24 privacy masks per camera. Note: There may be a small difference in size of the privacy mask area depending on whether local output or the web browser is used.

  • Page 32: Intelligent Tracking

    Note: The active zoom ratio is the magnification level the camera will zoom into when motion is detected. 7. Click Save to save changes. Clear PTZ configurations Use the PTZ configurations menu to clear all presets, preset tours, shadow tours, privacy masks, PTZ limits, scheduled tasks, and park actions.

  • Page 33: Prioritize Ptz

    2. Select Enable Intelligent Tracking. 3. Using the PTZ control buttons, point the camera at the desired area, or select a predefined preset position, where you want to set intelligent tracking. 4. Set the duration time. This is the time during which the camera follows the moving object or person.

  • Page 34: Overlay Text

    2. Select Network or RS-485 from the drop-down list. 3. Set the delay time (the range is between 2 and 200 s). 4. Click Save to save changes. Overlay text You can add up to eight lines of text on screen. This option can be used, for example, to display emergency contact details.

  • Page 35: Video Image

    Figure 8: Text overlay menu To add on-screen text: 1. From the menu toolbar, click Camera Configuration > Image > Settings. 2. Select the check box for the first line of text and enter the desired text in the text box.
  • Page 36 Figure 9: Camera image settings menu Parameter Description 1. Image Adjustment Brightness, Contrast Modifies the different elements of picture quality by adjusting the Saturation, Sharpness position of the values for each of parameter. 2. Exposure Settings Exposure Mode The Exposure Mode can be set to Auto, Iris Priority, Shutter Priority, and Manual.
  • Page 37 Parameter Description Slow Shutter The shutter speed controls the length of time that the aperture is open to let light into the camera through the lens. A slow shutter speed means it is open for longer. Select On or Off. Slow Shutter Level Slow Shutter is enabled, use this feature to adjust the shutter speed.

  • Page 38: Osd

    Parameter Description Fluorescent Lamp: Apply for scene where there are fluorescent lamps installed near the camera. Sodium Lamp: Apply for scene where there are incandescent lamps near the camera. ATW: White balance is continuously being adjusted in real-time according to the color temperature of the scene illumination. Auto: White balance is determined automatically.
  • Page 39 Figure 10: OSD settings menu To position the date/time and name on screen: 1. From the menu toolbar, click Camera Configuration > Image > Settings. 2. Select the Display Name box to display the camera’s name on screen. You can modify the default name in the text box of Camera Name.

  • Page 40: Image Parameters Switch

    Image parameters switch You can configure Link to Preset Scheduled-Switch in this interface. Link to Preset: Set the time period and linked scene for the preset and check the corresponding checkbox to go to the linked scene in the configured time period. Scheduled-Switch: Set the time period and linked scene and it will go to the linked scene in the configured time period when you check the corresponding checkbox.

  • Page 41: Motion Detection Alarms

    Motion detection alarms You can define motion detection alarms to detect motion when the camera is not moving. A motion detection alarm refers to an alarm triggered when the camera detects motion. However, the motion alarm is only triggered if it occurs during a programmed time schedule.
  • Page 42 2. Select Enable Motion Detection. Select Enable Dynamic Analysis for Motion you want to see in live view where the detected motion has occurred. Note: Deselect the “Enable Motion Detection” option to disable the motion detection alarm. 3. Click Draw Area.

  • Page 43: Tamper-Proof Alarms

    Tamper-proof alarms You can configure the camera to trigger an alarm when the lens is covered and to take an alarm response action. To set up tamper-proof alarms: 1. From the menu toolbar, click Camera Configuration > Alarm/Event Setup > Tamper-proof.

  • Page 44: Alarm Output

    2. Select the Alarm Input No. and the Alarm Type. The alarm type can be NO (Normally Open) or NC (Normally Closed). Enter a name for the alarm input. 3. Set the arming schedule for the alarm input. See “Motion detection alarms” on page 39 for more information on scheduling.

  • Page 45: Exception Alarms

    2. Select one alarm output channel from the Alarm Output drop-down list. You can also set a name for the alarm output. 3. The delay time can be set to 5 s, 10 s, 30 s, 1 min, 2 min, 5 min, 10 min or Manual. The delay time refers to the time duration that the alarm output remains in effect after alarm occurs.

  • Page 46: Audio Exception Detection

    • Invalid Login: Wrong user ID or password used to login to the cameras. To define exception alarms: 1. From the menu toolbar, click Camera Configuration > Alarm/Event Setup > Exception. 2. Under Notification Type, select one of the exception alarms from the drop-down list.

  • Page 47: Face Detection

    2. Check Enable for Audio Loss Exception. 3. Check Enable for Sudden Increase of Sound Intensity Detection and set the sensitivity and sound intensity threshold. 4. Select Sudden Decrease of Sound Intensity Detection and set the sensitivity. 5. Set the arming schedule for the alarm input. See “To set up motion detection” on page 39 on page for more information.
  • Page 48 To set up face detection: 1. From the menu toolbar, click Camera Configuration > Alarm/Event Setup> Face Detection. 2. Select Enable Face Detection. 3. Select Enable Dynamic Analysis for Face Detection if you want the face detected to be marked with a green rectangle in live view. Note: if you do not want the detected face marked with the green frame, select Disable from...

  • Page 49: Intrusion Detection

    Trigger Alarm Output Trigger external alarm outputs when an event occurs. Select one of the options: Select Trigger Alarm Output, A->1, or A- >2. Note: This option is only supported by cameras that support alarm output. 7. Click Save to save changes. Intrusion detection You can set up an area in the surveillance scene to detect when intrusion occurs.

  • Page 50: Line Crossing Detection

    identified as detection objects. If Vehicle is selected, only vehicles will be identified as detection objects. 5. Set the arming schedule for the intrusion detection. The arming schedule configuration is the same as that for motion detection. See “Motion detection alarms”...
  • Page 51 2. Select Enable to enable the function. 3. Select Draw Area and a crossing plane will show on the image. 4. Click the line and two red squares appear at each end. Drag one of the red squares to define the arming area. Select the direction as A<->B, A ->B, or B->A from the drop down menu: A<->B: Only the arrow on the B side is displayed.

  • Page 52: Region Entrance Detection

    Trigger Alarm Output Trigger external alarm outputs when an event occurs. Select one of the options: Select Trigger Alarm Output, A->1, or A->2. Note: This option is only supported by cameras that support alarm output. 10. Click Save to save changes. Region entrance detection This function detects people, vehicles or other objects that enter a designated region from outside the designated region.

  • Page 53: Region Exiting Detection

    7. Set the arming schedule for the region entrance detection. The arming schedule configuration is the same as that for motion detection. See “Motion detection alarms” on page 39 for more information. 8. Select the actions to be used for the region entrance detection. The options are: Notify Surveillance Center Send an exception or alarm signal to remote management software when an event occurs.

  • Page 54: Rs-485 Settings

    to four areas are supported. Click Clear to clear the areas you have drawn. The designated region parameters can be set up separately. Note: The area can only be quadrilateral. 4. Select the region to be configured. Sensitivity: The sensitivity value defines the size of the object that can trigger the alarm.

  • Page 55: Recording Schedule

    2. Select the RS-485 port parameters. Note: The Baud Rate, PTZ Protocol and PTZ Address should be the same as the PTZ camera parameters. 3. Click Save to save changes. Recording schedule You can define a recording schedule for the camera in the “Record Schedule” window. The recording is saved on to the SD card or NAS in the camera.
  • Page 56 2. Select the pre and post-record times. 3. Enable overwrite, if required. 4. Select the stream type (main stream, substream, or third stream). 5. Click the Enable check box to enable recording. Note: To disable recording, deselect the option. 6. Select one of the record types to record from the drop-down list box: •...

  • Page 57: Format Storage Devices

    Format storage devices Use the storage management window to display the capacity, free space available, and the working status of the HDD of the NAS and the SD card in the camera. You can also format these storage devices. Before formatting the storage device, stop all recording. Once formatting is completed, reboot the camera as otherwise the device will not function properly.

  • Page 58: Nas Settings

    NAS settings You can use a network storage system (NAS) to remotely store recordings. To configure record settings, please ensure that you have the network storage device within the network. The NAS disk should be available within the network and correctly configured to store the recorded files, log files, etc.
  • Page 59 To set up snapshots: 1. From the menu toolbar, click Camera Configuration > Storage > Snapshot. 2. Check Enable Timing Snapshot to enable continuous snapshots. Check the Enable Event-triggered Snapshot to enable event-triggered snapshots. 3. Select the snapshot format (JPEG only), resolution and quality. 4.

  • Page 60: Camera Management

    Camera management This chapter describes how to use the camera once it is installed and configured. The camera is accessed through a web browser. User management This section describes how to manage users. You can:  Add or delete users ...
  • Page 61 Types of users A user’s access privileges to the system are automatically defined by their user type. There are three types of user:  Admin: This is the system administrator. The administrator can configure all settings. Only the administrator can create and delete user accounts. Admin cannot be deleted.

  • Page 62: Rtsp Authentication

    5. Assign the user a password. Passwords can have up to 16 alphanumeric characters. 6. Assign permissions to users. Basic permissions Camera permissions Remote parameter settings Remote live view Remote log search/Interrogate working Remote PTZ control status Remote manual record Remote upgrade/format Remote playback Remote two-way audio...
  • Page 63 2. Under RTSP Authentication, select digest digest/basic to choose RTSP authentication type. 3. Click Save to save the changes. To define web authentication: 1. From the menu toolbar, click Camera Configuration > Security > Authentication. 2. Under Authentication, select digest digest/basic to choose web authentication type.

  • Page 64: Ip Address Filter

    IP address filter This function permits you to restrict the IP addresses that can be accessed by the camera. To define an IP address filter: 1. From the menu toolbar, click Camera Configuration > Security > IP Address Filter. 2. Check the Enable checkbox.
  • Page 65 2. Check the checkbox of Enable Invalid Login Lock. 3. Click Save to save changes. Note: 1. The IP address will be locked if the admin user performs seven failed user name/password attempts (10 attempts for the operator/user). 2. If the IP address is locked, you can try to login the device after five minutes. Restore default settings Use the Default menu to restore default settings to the camera.
  • Page 66 Only the new features are added with their default settings. To upgrade the firmware through the web browser: 1. Download on to your computer the latest firmware from our web site at: www.interlogix.com/library 2. In the Camera Configuration folder, select the System tab.
  • Page 67 System service To set the live view connection: 1. From the menu toolbar, click Camera Configuration > System > System Service. 2. Input a number in text field as the upper limit of the remote connection number. For example, when you specify the remote connection number as 10, then the 11th remote connection cannot be established.
  • Page 68 Camera operation This chapter describes how to use the camera once it is installed and configured. Logging on and off You can easily log out of the camera browser window by clicking the Logout button on the menu toolbar. You will be asked each time to enter your user name and password when logging in.
  • Page 69 Figure 15: Playback window Name Description Playback button Click to open the Playback window. Search calendar Click the day required to search. Search Start search. Set playback time Input the time and click to locate the playback point. Control playback Click to control how the selected file is played back: play, stop, slow and fast forward playback.
  • Page 70 Name Description Recording type The color code displays the recording type. Recording types are schedule recording, alarms recording and manual recording. The recording type name is also displayed in the current status window. To play back recorded video 1. Select the date and click the Search button.
  • Page 71 Searching event logs You must configure NAS or insert a SD card in the PTZ camera to be able to use the log functions. The number of event logs that can be stored on NAS or SD card depends on the capacity of the storage devices.
  • Page 72 Figure 16: Log window 1. Major Type 4. Start search 5. Export searched logs 2. Minor Type 3. Start and end search time You can search for recorded logs by the following criteria: Major type: There are three types of logs: Alarm, Exception, and Operation. You can also search all.
  • Page 73 To search logs: 1. Click in the menu toolbar to display the Log window. 2. In the Major Type and Minor Type drop-down lists, select the desired options. 3. Select start and end time of the log. 4. Click Search to start your search.
  • Page 74 Note: This feature can vary depending on the camera model. Using presets Presets are predefined locations of a PTZ dome camera that allow you to quickly move the PTZ dome camera to a desired position. You can only call up the predefined presets. For instance, preset 99 is the “Start auto scan”.
  • Page 75 2. Use the PTZ directional buttons to move the camera to the desired position. 3. Click to finish the setting of the current preset. 4. You can click to delete the preset. To call a preset: 1. Select a defined preset from the list. 2.
  • Page 76 Using shadow tours A shadow tour is a memorized series of pan, tilt, zoom, and preset functions. You can configure up to four shadow tours. To set a shadow tour: 1. In the PTZ control panel, click to enter the shadow tour list. 2.
  • Page 77 Index 802.1x parameters, 18 Invalid access lock, 62 IP address limit access, 62 Alarm input and outputs, 41 Alarm types motion detection, 39 Alarms Live view parameters, 12 HDD error, 43 Local configuration, 12 HDD full, 43 Log on and off, 66 illegal login, 43 Logs IP address conflicted, 43...
  • Page 78 park actions, 28 schedule tasks, 26 Tamper-proof alarms, 41, 45, 47, 48, 50, 51, 52 TCP/IP parameters, 16 Text overlay, 32 QoS parameters, 18 Time format set up, 36, 38 Tracking moving object, 30, 31 Reboot camera, 64 Record file settings, 12 UPnP parameters, 18 Recording User settings, 58...
