Overview Of The Camera Web Browser - Interlogix TVP-5101 Configuration Manual

Overview of the camera web browser

The camera web browser lets you view, record, and play back recorded videos on the
optional SD card as well as manage the camera from any PC with Internet access. The
browser's easy-to-use controls give you quick access to all camera functions. See
Figure 1 below.
If there is more than one camera connected over the network, open a separate web
browser window for each individual camera.
Figure 1: Web browser interface
Name
1. Live view
2. Playback
3. Picture
4. Log
5. Configuration
6. Viewer
7. Current user
8. Logout
9. Start/stop live
view
10. Capture
TruVision IP Compact PTZ Camera Configuration Manual
Description
Click to view live video.
Click to play back video.
Click to search for evet pictures and continues pictures
Click to search for event logs. There are three main types:
Alarm, Exception, and Operation.
Click to display the configuration window for setting up the
camera.
View live video. Time, date and camera name are displayed
here.
Displays current user logged on.
Click to log out from the system. This can be done at any
time.
Click to start/stop live view.
Click to take a snapshot of the video. The snapshot will be
saved to the default folder in JPEG (or BMP) format. The
directory of the folder can be set in Local Configuration
>Browser Configuration.
9
