ATEN Multi-View KVMP Switch User Manual page 18

TM
Multi-View KVMP
No. Component
6 Direction /
Function buttons
7 Console Audio
Ports
8 USB 2.0
Peripheral Port
9 IR Receiver
8
Switch User Manual
Use these buttons to:
Switch between different preset configurations (Fn1 to
Fn4). For details about Function modes, see Preset
Configuration, page 44.
Cycle through the OSD Menu/selection. See IR
Remote Control, page 11 for details.
Your speakers and microphone plug in here.
Note: When both the front-panel and rear-panel audio
ports are used, the front panel takes priority.
USB 2.0 peripherals (printers, scanners, etc.) plug into this
port.
This receives signals from the IR remote control.
Description
