ATEN Multi-View KVMP Switch User Manual page 71

Setting
Expansion
Control Station
Auto Scan
Auto Scan Duration
Auto Scan Mode
EDID Mode
Options
Daisy Chain / Cascade Sets the Multi-View KVMP
Station 1 / Station 2 /
Station 3 / Station 4
Enable / Disable
5s / 10s / 15s / 30s /
60s / 90s
Cycle / Powered-on
PC
Display A / Display B /
Remix / ATEN Default
Chapter 5. OSD Operation
Description
deployment type.
This setting is only available when
Expansion is set to Daisy Chain.
Select a daisy-chained secondary
station for keyboard and mouse
control.
Enable this function to have the Multi-
TM
View KVMP Switch cycle from port to
port at the defined Auto Scan Duration.
This gives users an automated way of
viewing all the computers connected to
the ports.c
Double-click the mouse wheel to switch
to the next port.
This setting is only available when Auto
Scan is enabled. Sets the duration that
a port has KVM focus before the focus
switches to the next port.
This setting is only available when Auto
Scan is enabled.
Cycle: Sets the Auto Scan to cycle
through all computers.
Powered on: Sets the Auto Scan to
only scan powered on computers.
Display A / Display B: This mode
sends the EDID of the selected
display (Display A or B) to all
connected sources.
Note: When an error occurs and
the video can not be displayed
using the specified EDID mode, the
Multi-View KVMP
automatically default the EDID
mode to ATEN Default.
Remix: This mode sends the
optimum EDID to all connected
displays.
ATEN Default: This mode sends
ATEN-predefined EDID (4096 x
2160 @30Hz for CM1284;1920 x
1080 @60Hz for CM1164A) to the
connected sources.
TM
Switch's
TM
Switch will
61
