User Manual
Ascom Myco Smartphone
8 Proximity sensor
3.1.6 Proximity Sensor, page 10
9 Multifunction 1 /Alarm button
3.1.7 Multifunction, and Alarm Button, page 10
10 Top display
3.1.8 Top Display, page 10
11 Color-coded LED priority beacon
11.2 Color-Coded LED Signals, page 68
12 Loudspeaker
13 Rear microphone
14 Camera/Barcode reader (13. Camera and Gallery on page 81.)
15 GSM antenna
16 Battery cover lock
17 Battery Pack
18 Clip
19 WLAN antenna, and GPS antenna
20 Color pad for clip (3.1.10 Color Pad for Clip on page 13.)
21 Back button 2
22 Overview button
23 Ascom IR location
1. This feature is system dependent
2. Designated hardware button on Ascom Myco 2, software button at the bottom of the screen on earlier models.
3. Designated hardware button on Ascom Myco 2, software button at the bottom of the screen on earlier models.
4. Only available for Ascom Myco 2.
3.1.1

Home Button

• Press to return to the Alert view (see
• Press to wake the display from sleep mode (see
Sleep, page 14). The Power button can also be used for this functionality.
3.1.2

Volume Button, Up and Down

• Press up to increase, or press down to decrease the speaker and loudspeaker volume (see
the Volume, page 15).
• Press the volume down button repeatedly to mute notification- or call sounds (see
or Silent Mode, page
To specify the default volume, see
3.1.3

Power Button

• Long press to turn the handset on (see
• Press to wake the display from sleep mode (see
Sleep, page 14). The Home button can also be used for this functionality.
TD 93066EN / 14 December 2018 / Ver. N
3
4
7.1 Alert View, page
15).
16.2.1 Volumes, page
4.1 Turn the Handset On, or Off, page
52).
4.2 Wake and Unlock the Handset, or Lock and Put It to
83.
4.2 Wake and Unlock the Handset, or Lock and Put It to
Handset Description
4.3 Adjust
4.4 Use Vibrator Only,
13).
9
