Specifications
Power size
N55k T7
N75k T7
N90k T7
N110 T7
N132 T7
N160 T7
N200 T7
N250 T7
N315 T7
Table 8.7 Fuse Options for 525–690 V Frequency Converters
For UL compliance, use the Bussmann 170M series fuses for units supplied without a contactor-only option. See Table 8.9 for
SCCR ratings and UL fuse criteria if a contactor-only option is supplied with the frequency converter.
8.7.2 Short Circuit Current Rating (SCCR)
If the frequency converter is not supplied with a mains
disconnect, contactor or circuit breaker, the Short Circuit
Current Rating (SCCR) of the frequency converters is
8 8
100000 amps at all voltages (380–690 V).
If the frequency converter is supplied with a mains
disconnect, the SCCR of the frequency converter is 100,000
amps at all voltages (380–690 V).
If the frequency converter is supplied with a circuit
breaker, the SCCR depends on the voltage, see Table 8.8:
D6h frame
D8h frame
Table 8.8 Frequency Converter Supplied with a Circuit Breaker
If the frequency converter is supplied with a contactor-only
option and is externally fused according to Table 8.9, the
SCCR of the frequency converter is as follows:
D6h frame
D8h frame (not
including the
N250T5)
D8h frame
(N250T5 only)
Table 8.9 Frequency Converter Supplied with a Contactor
1) With a Bussmann type LPJ-SP or Gould Shawmut type AJT fuse.
450 A max fuse size for D6h and 900 A max fuse size for D8h.
2) Must use Class J or L branch fuses for UL approval. 450 A max fuse
size for D6h and 600 A max fuse size for D8h.
68
Bussmann PN Siba PN
170M2616 20 610 31.160
170M2619 20 610 31.315
170M2619 20 610 31.315
170M2619 20 610 31.315
170M2619 20 610 31.315
170M4015 20 620 31.550
170M4015 20 620 31.550
170M4015 20 620 31.550
170M4015 20 620 31.550
415 V 480 V 600 V
120000 A 100000 A 65000 A
100000 A 100000 A 42000 A
415 V 480 V 600 V
1) 2)
IEC UL UL
100000 A 100000 A 100000 A 100000 A
100000 A 100000 A 100000 A 100000 A
100000 A Consult Not applicable
factory
