Danfoss VLT AutomationDrive FC 302 Operating Instructions Manual page 43

Application Set-up Examples
FC
+24 V 12
+24 V 13
D IN 18
19
D IN
20
COM
27
D IN
29
D IN
32
D IN
33
D IN
D IN
37
+10 V 50
+
A IN
53
A IN
54
COM
55
-
A OUT
42
4 - 20mA
COM
39
U - I
A53
Table 6.4 Analog Speed Reference (Current)
FC
+24 V 12
+24 V 13
D IN 18
D IN 19
COM 20
D IN 27
D IN 29
D IN 32
D IN 33
D IN
37
+10 V 50
A IN
53 ≈ 5kΩ
A IN
54
COM
55
A OUT
42
COM
39
U - I
A53
Table 6.5 Speed Reference (Using a Manual Potentiometer)
MG34U402
Operating Instructions
Parameters
Function Setting
Parameter 6-12 T 4 mA*
erminal 53 Low
Current
Parameter 6-13 T 20 mA*
erminal 53 High
Current
Parameter 6-14 T 0 Hz
erminal 53 Low
Ref./Feedb. Value
Parameter 6-15 T 50 Hz
erminal 53 High
Ref./Feedb. Value
* = Default Value
Notes/comments:
D IN 37 is an option.
Parameters
Function Setting
Parameter 6-10 T 0.07 V*
erminal 53 Low
Voltage
Parameter 6-11 T 10 V*
erminal 53 High
Voltage
Parameter 6-14 T 0 Hz
erminal 53 Low
Ref./Feedb. Value
Parameter 6-15 T 1500 Hz
erminal 53 High
Ref./Feedb. Value
* = Default Value
Notes/comments:
D IN 37 is an option.
Danfoss A/S © 06/2015 All rights reserved.
FC
+24 V 12
+24 V 13
D IN 18
D IN 19
COM 20
D IN 27
D IN 29
D IN 32
D IN 33
D IN
37
+10 V 50
A IN
53
A IN
54
COM
55
A OUT
42
COM
39
Table 6.6 Speed Up/Down
Speed
Reference
Start ( 18)
Freeze ref ( 27)
Speed up ( 29 )
Speed down ( 32 )
Illustration 6.1 Speed Up/Down
Parameters
Function Setting
Parameter 5-10 T [8] Start*
erminal 18
Digital Input
Parameter 5-12 T [19] Freeze
erminal 27 Reference
Digital Input
parameter 5-13 T [21] Speed
erminal 29 Up
Digital Input
parameter 5-14 T [22] Speed
erminal 32 Down
Digital Input
* = Default Value
Notes/comments:
D IN 37 is an option.
41
6 6
