Introduction
1 1
1.4.2 Interior Views
1
15
13
(IP 21/54
NEMA 1/12)
Illustration 1.1 D1 Interior Components
NOTICE
For location of TB6 (terminal block for contactor), see chapter 4.6 Motor Connection.
4
VLT® AutomationDrive FC 302
10
11
8
9
16
14
13 (IP 20/Chassis)
Danfoss A/S © 06/2015 All rights reserved.
1
6
2
5
3
1 LCP (local control panel)
2 RS485 serial bus connector
3 Digital I/O and 24 V power
supply
4 Analog I/O connector
5 USB connector
6 Serial bus terminal switch
12
7 Analog switches (A53),
(A54)
8 Relay 1 (01, 02, 03)
Illustration 1.2 Close-up View: LCP and Control Functions
10
11
7
4
8
9
9 Relay 2 (04, 05, 06)
1 Lifting ring
0
1 Mounting holes
1
1 Cable clamp (PE)
2
1 Earth (ground)
3
1 Motor output terminals 96 (U),
4 97 (V), 98 (W)
1 Mains input terminals 91 (L1),
5 92 (L2), 93 (L3)
1 TB5 (IP21/54 only). Terminal
6 block for anti-condensation
heater
