- Page 1 Digital Signage Display Kiosk | Portrait | Lockable Actual product may vary from photos User Manual SKU#: DSIGNAGESTND For the latest information and specifications visit www.startech.com/DSIGNAGESTND Manual Revision: 11/21/2019...
- Page 2 This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual...
-
Page 3: Safety Statements
électrique, de chute ou de sécurité 安全対策 • ケ ーブル （電源ケーブルと充電ケーブルを含む） は、 適切な配置と引き回し を行い、 電気障害やつまづきの危険性など、 安全上のリスクを回避するよう にしてください。 Misure di sicurezza • I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o pericoli per la sicurezza. Säkerhetsåtgärder • K ablar (inklusive elkablar och laddningskablar) ska dras och placeras på så sätt att risk för snubblingsolyckor och andra olyckor kan undvikas. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 4: Warning Statements
Varningsmeddelanden • Se till att du monterar produkten i enlighet med instruktionerna. • Överskrid inte produktens viktkapacitet. Överbelastning av produkten kan orsaka skada på person eller egendom. Denna produkt har stöd för följande vikter: 80 kg. • Produkten är endast avsedd för användning inomhus och ska inte användas utomhus. • Detta skåp är extremt tungt. Försök aldrig flytta på skåpet eller lyfta det utan hjälp. • Risk för vältning! • Håll vätskor borta från skåpet. Avertissements • Assemblez ce produit conformément aux instructions. • Ne dépassez pas la capacité pondérale du produit. Une surcharge du produit peut entraîner des blessures ou des dommages matériels. Ce produit peut supporter 80 kg. • Ce produit est uniquement destiné à une utilisation en intérieur et ne doit pas être utilisé à l’extérieur. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 5 • Beachten Sie bei der Montage dieses Produkts die Montageanweisungen. • Überschreiten Sie nicht die Tragkraft dieses Produkts. Ein Überladen dieses Produkts kann zu Verletzungen oder zur Beschädigung des Produkts führen. Dieses Produkt ist für folgendes Gewicht geeignet: 80 • Dieses Produkt ist nur zum Gebrauch in Innenräumen vorgesehen und sollte nicht im Freien verwendet werden. • Dieses Gehäuse ist extrem schwer. Versuchen Sie niemals, dieses Gehäuse ohne Hilfe zu bewegen oder anzuheben. • Kippgefahr! Dieses Produkt ist freistehend und von Natur aus instabil, insbesondere wenn Geräte darin montiert sind. Daher muss es mit den mitgelieferten oder geeigneten Verankerungselementen sicher am Boden befestigt werden. • Halten Sie Flüssigkeiten von diesem Gehäuse fern. • Das mit diesem Produkt gelieferte Befestigungsmaterial für die Bodenverankerung ist für massive Betonböden ausgelegt. Wenn Sie nicht über die erforderlichen Kenntnisse verfügen, um die Eignung der mitgelieferten Hardware für Ihren Boden zu bestimmen oder um dieses Produkt sicher zu verankern, wenden Sie sich an einen Fachmann, um den Stand zu verankern oder um spezifische Anweisungen für Ihren Bodentyp zu erhalten. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 6 Advertencias de uso • Asegúrese de ensamblar este producto según las instrucciones. • Asegúrese de no exceder la capacidad de peso de este producto. La sobrecarga de este producto puede causar lesiones personales o daños en la propiedad. Este producto tiene capicidad para el siguiente peso: 80 kg. • El uso de este producto es solo para interiores y no debe utilizarse en exteriores. • La caja es extremadamente pesada. Nunca intente mover o alzar esta caja sin la debida asistencia de otra persona. • ¡Peligro de vuelco! Este producto es autoportante y por consiguiente es inestable, especialmente cuando tenga equipo instalado. Por lo tanto, debe fijarse firmemente al suelo utilizando elementos de anclaje adecuados o los accesorios suministrados. • Mantenga cualquier líquido lejos de la caja. • Los anclajes para suelo incluidos con el producto están diseñados para suelos de hormigón macizo. Si usted carece de la experiencia necesaria para determinar si los accesorios suministrados son adecuados para To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 7 必ず取扱説明書に従って本製品の組み立てを行って下さい。 • 本製品で定められた最大積載重量を超えないようにして下さい。 最大積載重量をオーバーした 場合、 怪我をする恐れや器物破損の恐れがあります。 本製品は、 モニター1台あたり80kgまで支 持できます。 • 本製品は、 室内での使用を想定しています。 戸外では使用しないで下さい。 • 本製品は、 非常に重いエンクロージャです。 絶対に一人で持ち上げたり動かしたり しないで下さ い。 • 転倒注意 ！ 本製品から複数のコンポーネントが突き出した状態にしておく とエンクロージャが転 倒する恐れがあります。 転倒リスクを回避するために、 エンクロージャからはコンポーネントが突 き出ないようにして下さい。 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 8 • 液体物をエンクロージャに近づけないようにして下さい。 • 本製品は自立タイプのため、 機器を取り付けた状態では本質的に不安定です。 付属または適切な 固定用金具を使って床にしっかりと固定してください。 • 付属の固定用金具を使って、 コンクリート製の床に固定することができます。 付属の固定用金具が お使いの床に適合するかどうか判断できなかったり、 本製品を安全に固定する方法が分からない 場合は、 専門の業者に本スタンドを固定してもらうか、 お使いの床のタイプにふさわしい取付方 法について相談して下さい。 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 9: Table Of Contents
Assembling the Display Kiosk ..............18 Attaching the Display Brackets (Flush) ..........34 Attaching the Display Brackets (Recessed) ........35 Spacer Combinations ..........................38 Mounting the Display ................39 Securing the Display Kiosk ..............43 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 10: Product Diagram
Product Diagram Front View To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 11 End Caps Cable Bracket Upper Column Upper Base Board Cross Bar Lower Column Display Bracket Cabinet Cable Ties Lower Base Board To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 12: Product Information
Product Information Package Contents Lower Base Board Lower Columns Qty: 1 Qty: 2 Lower Column Caps Cabinet Qty: 4 Qty: 1 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 13 Upper Base Board Upper Column Left Qty: 1 Qty: 1 Upper Column Right End Caps Qty: 1 Qty: 2 Cross bars Display Brackets Qty: 2 Qty: 2 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 14 Locking Brackets Qty: 1 Qty: 2 Cable Clips Screw Caps Qty: 2 Qty: 2 M10 x 25 mm Screws M6 x 12 mm Screws Qty: 4 Qty: 10 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 15 Qty: 8 Qty: 2 M4 x 6 mm Screws Screws Qty: 2 Qty: 2 M5 x 14 mm Screws M6 x 14 mm Screws Qty: 4 Qty: 4 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 16 M8 x 30 mm Screws Qty: 4 Qty: 4 M8 x 50 mm Screws Rectangular Washers Qty: 4 Qty: 4 Cable Ties M6/M8 Wrench Qty: 2 Qty: 1 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 17 4 mm Hey Key 6 mm Hex Hey Qty: 1 Qty: 1 5 mm Hey Key Small Spacers’ Qty: 1 Qty: 8 Large Spacers Floor Anchor Qty: 8 Qty: 1 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 18: Technical Specifications
Technical Specifications 80 kg (176 lb) Total Weight 45” - 55” (1143 mm to 1397 mm) Screen Size Requirements Phillips Head Screwdriver x 1 • To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 19: Assembling The Display Kiosk
Align the bottom of the Lower Columns (x 2) with the End Caps. Make sure that the Bracket on the Lower Columns are at the top and facing inwards. Insert the Lower Columns into the End Caps. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 20 Lower Base Board and End Caps and into the Lower Column. Using the 6 mm Hex Key tighten the M10 x 25 mm Screws, being careful not to over-tighten. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 21 Using the included Key, unlock the Cabinet Door. Align the four interior Screw Hole inside the Cabinet with the four Screw Holes on the center of the Lower Base Board. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 22 Using the Phillips Head side of the 5 mm Hex Key, tighten the M6 x 12 mm Screws. Be careful not to over-tighten the M6 x 12 mm Screws. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 23 Cabinet. Make sure that the two Screw Holes on the Upper Base Board align with the two Screw Holes on the Brackets on the Lower Columns. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 24 Using the Phillips Head side of the 5 mm Hex Key, tighten the M6 x 12 mm Screws. Be careful not to over-tighten the M6 x 12 mm Screws. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 25 Upper Base Board. Insert two M6 x 12 mm Screws through the two Screw Holes on the inside of the Cabinet and up into the Upper Base Board. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 26 Lower Column that is protruding through the Upper Base Board. Note: Make sure that the Screw Holes on the side of the Up- per Column are facing inward. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 27 Insert two M8 x 60 mm Screws through the Screw Holes on the Upper Column and the Screw Holes on the Lower Column and into the Nuts on the opposite side. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 28 Column is attached to the Lower Column). Snap the Lower Column Cap into the Holes (x 4) in the Upper Base Plate securing the Lower Column Cap in place. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 29 Installing the Lower Column Cap Insert the End Cap on the top of the Upper Column. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 30 Screw Holes on the Upper Columns. Note: Make sure that the two Screw Holes in the center of the Cross Bar are facing towards the front of the Display Kiosk. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 31 Screw Holes on the Cross Bar Bracket and into the Upper Column. Using the 4 mm Hex Key tighten the M6 x 15 mm Screws. Be Careful not to over-tighten the M6 x 15 mm Screws. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 32 Cross Bar. Make sure that the Screw Holes on the bottom of the Cable Bracket are also aligned with the Screw Holes on the Upper Base Board, located on either sides of the Cable Management Hole. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 33 Using the Phillips Head tip on the 5 mm Hex Key tighten the M4 x 6 mm Screws. Be careful not to over-tighten the M4 x 6 mm Screws. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 34 Attach the two Cable Clips into the Holes in the center of the Cable Bracket. Make sure to attach the Cable Clips to the back of the Cable Bracket so that the cables are hidden when routing the cables. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 35: Attaching The Display Brackets (Flush)
Screw Hole on the Display Bracket. Insert the appropriate Screw through the Screw Hole in the Square Washer and Display Bracket and into the Screw Hole on the Display. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 36: Attaching The Display Brackets (Recessed)
Select the appropriate Mounting Hardware for mounting the Display Brackets (M5 x 14 mm, M6 x 14 mm, M6 x 30 mm, M8 x 30 mm, or M8 x 50 mm and Spacers). To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 37 Square Washer, Display Bracket and Spacers and into the Screw Hole on the Display. Aligning the Spacers, Square Washer and Screw Using a Phillips Head Screwdriver tighten the Screw. Be careful not to over-tighten. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 38 Warning! Do not over-tighten the Screws. If you encounter resistance while you’re tightening the Screws, stop tighten- ing. Failure to do so could result in damage to the Display. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 39: Spacer Combinations
Spacer Combinations Screw Type Spacer Combination M6 x 30 mm M8 x 30 mm M8 x 50 mm To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 40: Mounting The Display
Lift the Display into position, aligning the Hooks on the Display Brackets with the Cross Bars. Attach the Hooks on the Display Brackets with the upper and lower Cross Bars. Attaching the Display to the Cross Bar To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 41 Bracket through the two Notches (under the M6 x 35 mm Screw) on the Display Bracket. Insert a Lock (sold separately) through the hole at the end of the Locking Bracket. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 42 Cross Bar. Feed the tip of the Cable Tie through the fastener and pull the end securing the Cable to the Cross Bar. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 43 Management Hole through the top of the Upper Base Board and connect them to the A/V Equipment or route them out the Cable Management Hole in the back of the Cabinet. Attaching the Cable Clips To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 44: Securing The Display Kiosk
Attaching the Floor Anchor To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 45 Note: Tipping Hazard! This product is freestanding and inherently unstable especially when equipment is mounted. Therefore, it must be securely attached to the floor using the supplied or appropriate anchoring hardware. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 46 Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
- Page 47 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
