5.1 Overview of Parameters

MODBUS
Address
Modicom
Hex
Format
1 40002
2 40003
3 40004
_5
4 40005
5 40006
6 40007
7 40008
8 40009
9 40010
A 40011
B 40012
C 40013
D 40014
5 - 2
Item
0. System Parameters: 0001 – 00FF
Present date
Present time
Meter Constant
Meter Model
Total running time of the
meter
Firmware version
Firmware release date
Power system configuration 0: 3φ4W
Range
Year: 00–99
Month: 1–12
Date: 1–31
Week: Sun–Sat
Hour: 00–23
Minute: 00–59
Second: 00–59
3200
0: None
6: C501L
Day: 0–65535
Hour: 00–23
Minute: 00–59
0.0000 – 9.9999
Year: 00–99
Month: 1–12
Date: 1–31
Reserved
Data
Data Read (R) /
Unit Size
Type Write (W)
(byte)
Year,
byte 2 R/W
Month
Date,
byte 2 R/W
Week
Hour,
byte 2 R/W
Minute
word Second 2 R/W
uint P/kWh 2
word 2
uint Day 2
Hour,
byte 2
Minute
uint 2
Year,
byte 2
Month
word Date 2
word 2 R/W
R
R
R
R
R
R
R
