- Page 1 Raise3D N1/N2/N2+ Assembly and installation manual This work is licensed under a Creative Commons Attribution 4.0 International License. Table of Contents...
-
Page 2: Table Of Contents
What’s in the box? Raise3D DualDirect Raise3D SingleDirect Mechanical Installation What you need Raise3D DualDirect and Raise3D SingleDirect Raise3D N2 DualDirect Raise3D N2 SingleDirect Software Configuration Changing the E-step value Electronic Configuration Adjustment of the stepper driver current Installation manual Bondtech Raise3D V2.0... -
Page 3: Introduction
Introduction The Bondtech Raise3D DualDirect and SingleDirect extruder, which is developed by Bondtech, is the simplest way to increase the performance of your Raise3D N1/N2/N2+ machine in a matter of minutes. This new revolution in design utilizes the proven Bondtech Dual Drive Technology with precision CNC-manufactured parts. -
Page 4: Mechanical Installation
After the filament is removed, power off the printer. ● Start with uninstallation of the original extruder. Note that the two connectors are yellow and white in this case, but the colors may vary. Installation manual Bondtech Raise3D V2.0... - Page 5 “R”, so they don’t get mixed up. • Disconnect both cables from the motors. • Remove the 2 screws from the right and the left side with a 2,5mm hex wrench. Installation manual Bondtech Raise3D V2.0...
- Page 6 • Remove the 2 rear screws using a 2,5mm hex wrench. • Unscrew the 2 screws holding the cable chain, with a 2mm hex wrench. Installation manual Bondtech Raise3D V2.0...
- Page 7 • Remove the 2 screws (3mm hex wrench) holding the breakout board. • Remove the original extruder by pulling it straight up. • The removal of the original extruder is now done! Installation manual Bondtech Raise3D V2.0...
-
Page 8: Raise3D N2 Dualdirect
• The shims are marked with the appropriate revision. • Place the correct shim on the rear mount. • Firmly press down the DualDirect extruder. Support the printhead from underneath to avoid deflection of the linear shafts. Installation manual Bondtech Raise3D V2.0... - Page 9 (both the previous on the sides and the rear ones) carefully to prevent that the material crack, DO NOT OVERTIGHTEN!. • Cut existing cable ties to make it possible to re- arrange the cables. Installation manual Bondtech Raise3D V2.0...
- Page 10 • Remove the supplied 1x M2,5 screw. • Place the breakout board into the new holder. • Install the board holder. Note that the bottom screw is M2,5 and the upper one • Done! Installation manual Bondtech Raise3D V2.0...
- Page 11 • Connect the cable marked with “L” to the front motor. Use the adapter that has wires reversed, “L”. • Connect the cable marked with “R” to the rear motor. Use the adapter that has straight wires, “R”. Installation manual Bondtech Raise3D V2.0...
- Page 12 • To reverse two cables, you can use a sharp tool to lift the little plastic tab on the connector and gently pull the crimping contact out of the housing with your fingers. • Like this! Installation manual Bondtech Raise3D V2.0...
- Page 13 Reverse position 1 and 3. • Arrange the cables nicely and use cable tie to secure them. • Do the same on the bottom and cut of the ends. Installation manual Bondtech Raise3D V2.0...
- Page 14 • Done! • You are done with the installation of Raise3D DualDirect! Installation manual Bondtech Raise3D V2.0...
-
Page 15: Raise3D N2 Singledirect
• The shims are marked with the appropriate revision. • Place the correct shim on the rear mount. • Firmly press down the SingleDirect extruder. Support the printhead from underneath to avoid deflection of the linear shaft. Installation manual Bondtech Raise3D V2.0... - Page 16 (2,5mm hex wrench). Do not tighten the screws fully. Re-tighten the screws in turns afterwards, (both the previous on the sides and the rear ones) carefully to prevent that the material crack. ● Remove supplied 1x M2,5 screw. Installation manual Bondtech Raise3D V2.0...
- Page 17 • Place the breakout board into the new holder. • Install the board holder. Note that the bottom screw is the supplied M2,5 and the upper one M3. • Install the cable chain, use the old screws (2mm hex wrench). Installation manual Bondtech Raise3D V2.0...
- Page 18 • Do the same with the cable next to the first one. • Change positions of those two cables by pushing it back into place. Position 1 and 3 change position. • Like this! Installation manual Bondtech Raise3D V2.0...
- Page 19 • Use cable tie around the cables. • Cut off the end. • You are done with the installation of Raise3D SingleDirect! Installation manual Bondtech Raise3D V2.0...
-
Page 20: Software Configuration
1mm filament. The Raise3D E-step value needs to be updated to achieve the correct extrusion volume. The reason for this is that the Bondtech Dual Drive system has a different drive gear diameter and a gearing ratio. The increased E step value means that the extruder will feed the material with higher precision. - Page 21 • Click on More settings. • Click on Hardware. Installation manual Bondtech Raise3D V2.0...
- Page 22 • Click on Step per unit. • Click on E steps per unit. Installation manual Bondtech Raise3D V2.0...
- Page 23 ● Set the E step unit to 415. • Double check that the new value has been changed to 415. Done! Installation manual Bondtech Raise3D V2.0...
-
Page 24: Electronic Configuration
• Tip! Grind the tip on the probe to make it easier to do the adjustment. Shape the tip like a small flat screw driver. Installation manual Bondtech Raise3D V2.0... - Page 25 Now you can see the Vref voltage of the driver. • Turn the potentiometer carefully until you reach the value of 0,5V(500mV), clockwise increase, counter-clockwise decrease. • Repeat this for both stepperdrivers for the extruders (if you have a dual printer) Installation manual Bondtech Raise3D V2.0...
