- Page 1 HOW TO Install LGX® ACE and Mosquito on the Anycubic Kobra Difficulty Medium Steps Time Required 25 to 30 min PRODUCT PAGE Sections...
-
Page 2: Instructions Guide
2.5 mm hex key. You can now remove the toolhead assembly. Unscrew the countersunk M3 on the left side Unscrew the M3 screw on the front using a 2.5 using a 2 mm hex key. mm hex key. Page 2/9 www.bondtech.se... - Page 3 Pull the heater and thermistor out. Disconnect the stepper motor. Undo the screws holding the fan shroud. Remove the fan shroud. Undo the screw holding the bed probe. Undo the three screws holding the hotend heatsink. Page 3/9 www.bondtech.se...
- Page 4 Fasten the top right M3 screw using a 2 mm hex Add the hotend assembly to the extruder. Fasten the two M3 screws at the bottom using a 2 key. mm hex key. Page 4/9 www.bondtech.se...
- Page 5 M3x12 SHCS screws with a 2.5 mm hex key. fasten them. Add the screws holding the bed probe and fasten Disconnect the part cooling fan. Route the wire from the 5015 from the front to the them. back and connect it to the board. Page 5/9 www.bondtech.se...
- Page 6 2mm hex key. the included M3x20 SHCS and a 2.5mm hex key. Connect the toolhead connector. Turn the printer on its side, and make sure it’s Undo the two screws in the middle. unplugged. Page 6/9 www.bondtech.se...
- Page 7 Add the back panel to close it up again. Add the two screws and tighten them back down. fin Unplug the printer and the hardware is done! Check the Quick Start guide for slicer presets and printer settings. Page 7/9 www.bondtech.se...
-
Page 9: How To Get Help
We are available to help you with any questions or issues you may have. Simply go to our website where you can access our customer support and send us your questions or follow the provided link: https://www.bondtech.se/contact/#tab_technical-support-requests Page 8/9 www.bondtech.se...
