- Page 1 QUICK SETUP GUIDE PRO and LGX ® ® PRO 2.85 Extruders...
- Page 2 • 1x Bowden Interface Plug (with threaded metal push-fit); • 1x 2mm Hex Key (recommended tool); • 1x Product Line Information Brochure; • 1x Powered By Bondtech sticker. Also shipping with additional accessories: • 4x M3x23 mm Stud with 5mm Hex with M3x4 thread;...
- Page 3 Shore hardness between Shore hardness between Shore hardness between the drive gears. Shore hardness of ~95A 85 and 95A. 75 and 85A. 60 and 75A. or when you need more grip on rigid materials. bondtech.se Page 3...
- Page 4 Copperhead, Mosquito, Mosquito Magnum and Mosquito Magnum+ Air and Liquid. The interface Plug geometry supports modules like LGX ® ACE, ® Shortcut, LGX ® Bowden Adapter and LGX ® Revo Micro adapter. You can find the geometry of the Interface Plug HERE. bondtech.se Page 4...
- Page 5 The maximum operating temperature with the LGX PRO is ® 100°C with a stepper motor current lower than the maximum recommended current of 1A RMS. bondtech.se Page 5...
- Page 6 Reliability and Performance HARDENED STEEL DRIVETRAIN MAINTENANCE REQUIRED Make sure gears are always lubricated to prevent wear and clean the gears from debris every 100 hours of print time. RECOMMENDED SOFTWARE SETTINGS ® LGX PRO ® 2.85 Marlin Esteps Microstepping 1/16...
- Page 7 Reliability and Performance...
