HOW TO
Install LGX® Lite Arrow
for Creality
Difficulty
Medium
Steps
51
Time Required
25 to 40 min
Sections
1
Related Resources
Quick Start Guide
Required Tools
1.5mm Hex Key
2mm Hex Key
2.5mm Hex Key
Wrench
Utility Knife
Multimeter
Stock Items Reused
Toolhead PCB
4010 blower fan
PRODUCT PAGE
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bondtech LGX Lite Arrow
Summary of Contents for Bondtech LGX Lite Arrow
- Page 1 HOW TO Install LGX® Lite Arrow for Creality Difficulty Medium Steps Time Required 25 to 40 min PRODUCT PAGE Sections Related Resources Quick Start Guide Required Tools 1.5mm Hex Key 2mm Hex Key 2.5mm Hex Key Wrench Utility Knife Multimeter Stock Items Reused Toolhead PCB 4010 blower fan...
-
Page 2: Instructions Guide
Remove the cowling and disconnect the fan from Remove the bowden tube from the hotend. Remove the push fit coupler from the hotend the toolhead board. using the wrench from the printer tools. Page 2/9 www.bondtech.se... - Page 3 Separate the Arrow hotend mount from the Arrow Add the Arrow hotend mount to the top of the bed Add the hotend under the bed leveling sensor and extruder mount. leveling sensor. fasten them together using a 2mm hex key. Page 3/9 www.bondtech.se...
- Page 4 Remove the jig and the extruder mount. down. Add back the four M3x8 BHCS to the extruder Add the extruder mount to the bottom of the LGX Tighten the screws using a 2mm hex key. mount. Lite. Page 4/9 www.bondtech.se...
- Page 5 1.5 mm hex key. Remove the fan from the cowling. With a 2.5mm hex key, undo the M3x16 SHCS With a 2mm hex key, undo the M3x8 BHCS holding holding the cover. the fan shroud. Page 5/9 www.bondtech.se...
- Page 6 Add one M3x8 BHCS back through the toolhead 2mm hex key. board and fasten with a 2mm hex key. Reconnect the bed leveling sensor and part Add the LED to the cover. Add the cover back on. cooling fan. Page 6/9 www.bondtech.se...
- Page 7 With something small and sharp, extract the blue Disconnect the old extruder motor wires. Connect the LGX Lite and it’s done! Check the and yellow pin like shown here and swap them. Quick Start for settings and current adjustment. Page 7/9 www.bondtech.se...
-
Page 8: How To Get Help
We are available to help you with any questions or issues you may have. Simply go to our website where you can access our customer support and send us your questions or follow the provided link: https://www.bondtech.se/contact/#tab_technical-support-requests Page 8/9 www.bondtech.se...
