PARTS LIST

REF NO.
AC3 ASSY
PC BOARD
1700
PCB
CAPACITOR
J003(G)/CHA
C065
C007,C036,C039
C104,C110,C116,C198
C001,C002,C005,C006,C008-C012,C015,C016,
C018,C021,C046,C060-C062,C111-C113,C115,
C117,C120,C121,C154,C155,C156,C160,C168,
C170,C175,C177,C197,C199,C200
C150
C130,C134,C138,C142,C146,C152
C047
C151
C048,C063,C064
C129,C133,C137,C141,C145,C149
C101,C103,C106
C128,C132,C136,C140,C144,C148
C102
C150/U101
C108
u050(1)/gnd
C014
C080,C126,C127,C131,C135,C139,C143,C147,
C157
C013,C019
C022
C107
R094/
C180,C181
C017,C038
C003
COIL
L002
L100
WAFER/SOCKET
J001A,J002A
U022
J019
J009,J012,J022
J004
J011,J020
J001
DESCRIPTION
AC3 PCB ASSY (A0150C)
AC3 PCB (A0150C)
CC 25V 0.01U 20% RL
CC 25V 0.47uF +80/-20% 0
CC 50V 100pF 5% 0805 1.2
CC 50V 0.01U 10% 0805
CC 50V 0.1uF 20% 0805 1.
CC 50V 15pF 5% 0805 1.2x
CC 50V 220pF 10% 0805 1.
CC 50V 2200pF 10% 0805 1
CC 50V 33pF 5% 0805 1.2x
CC 50V 330pF 10% 0805 1.
CC 50V 3900PF 10% 0805
CC 50V 0.47U 20% RM
CC 50V 5600pF 10% 0805
CC 50V 82pF 5% 0805 1.2x
TRIMCAP 5.2-30P
CE 10V 100uF 20% RL 5x11
CE 10V 1000U 20% RL 8x16
CE 10V 470uF 20% RL 8x12
CE 16V 10uF 20% RL 4x7
CE 16V 100uF 20% RL 5x11
CE 16V 22uF 20% RL 5x5
CE 16V 47uF 20% RL 5x11
CE 25V 1000uF 20% RL
CE 25V 47uF 20% RL 5x11
CE 50V 1uF 20% RL 4x7
CTC 0/60 10pF 5% 0805
COIL 10UH 10% BL7.0
COIL 68UH 20% BL7
WAFER 10PIN P2.54 DUAL
PLCC SOCKET 44 PIN (4X11
3 PIN ST. WAFER
4P ST.WAFER
5P ST.WAFER
6P ST. WAFER
WF T8 DE 7PIN COULOMB
4
GTP-740
PART NO.
PCB-A0150C-AC3
1723-038A-0000
150E-103M-5-IF
150E-474Z-J-BD
150F-101J-J-BD
150F-103K-J-BD
150F-104M-J-BD
150F-150J-J-BD
150F-221K-J-BD
150F-222K-J-BD
150F-330J-J-BD
150F-331K-J-BD
150F-392K-J-BD
150F-474M-7-IJ
150F-562K-J-BD
150F-820J-J-BD
1551-0210-0
157C-107M-5-IU
157C-108M-5-O5A
157C-477M-5-OW
157D-106M-5-GM
157D-107M-5-IU
157D-226M-5-II
157D-476M-5-IU
157E-108M-5-X&
157E-476M-5-IU
157F-105M-5-GM
15CH-100J-J-BDL
1801-100K-M
1801-680M-M
2101-0831-0
2101-0841-0
2102-031S-004
2102-041S-004
2102-051S-004
2102-061S-004
2102-071S-004
