Adcom GTP-740 Service Manual page 22

PARTS LIST
REF NO.
0117
0110
0123
0108
0118
0124
0125
0151
0152
0185
0130
0163
0129
0107
0193
0191
0197
0198
0127
0184
0183
0171
0179
0178
0168
0173
0189
0177
0169
0174
0192
0182
0180
0170
0176
0172
0175
NOTE:
- The components identified by
Replace only with part number specified.
- *U : USA model only.
- *C : European model only.
- Capacitors : CP-Polystyrere, CM-Mylar,
CE-Electrolytic, CC-Ceramic.
- Resistors : RMF-Metal Film.
DESCRIPTION
POWER KNOB LENS
LENS,VOLUME GTP-740
REMOTE LENS
DISPLAY LENS GTP-740
LENS BUTTON ACTUATOR
LENS,LEDX8
LENS LEDX4
HEX STANDOFF M3X30.4
HEX STANDOFF M3X53.4
UP/DOWN KNOB ADAPTOR
PLASTIC FOOT
RUBBER PIN
FOAM STRIP 80X10X1MM
DISPLAY BEZEL GTP-740
LCD COVER SHEET
RUBBER PAD 12X18X13MM
IR JACK PLASTIC PLUG
FIBRE SHEET FOR A0150C
AC CORD 10/16A 250V 3X
CONN. ASSY 8P P2.5 L=50
CONN. ASSY 4P P2.5 L=130
CONN. ASSY 3P P2.5 L=110
CONN ASSY 9P P2.5 L=60
CONN ASSY 7P P2.5 L=70
CONN ASSY 2P P2.5 L=140
CONN ASSY 4P P2.5 L=150
CONN. ASSY 4P 2.5P L=50
CONN ASSY 6P P2.5 L=50
CONN ASSY 3P P2.5 L=50
CONN ASSY 5P P2.5 L=50
CONN ASSY 5P P2.5 L=90
CONN ASSY 12P P2.5 L=60
CONN ASSY 9P P2.5 L=90
CONN ASSY 3P P2.5 L=90
CONN ASSY 4P P2.5 L=110
CONN. ASSY 4P P2.5 L=50
CONN ASSY 5P P2.5 L=120
mark are critical for risk of fire and electrical shock.
22
GTP-740
PART NO.
3714-4906-0
3715-4100-0
3715-4506-0
3715-4700-0
3715-4800-0
3715-4900-0
3715-5000-0
4132-6691-0
4132-6701-0
4134-0151-0
4152-0481-0
4152-0501-0
4152-0661-0
4152-4191-0
4152-6111-0
4152-9061-0
4152-9071-0
4152-9091-0
7009-5470-0
7010-1030-0
7010-1040-0
7010-1050-0
7010-1470-0
7010-1480-0
7010-1490-0
7010-1500-0
7010-1510-0
7010-1520-0
7010-1530-0
7010-1540-0
7010-1550-0
7010-1560-0
7010-1570-0
7010-1580-0
7010-1590-0
7704-1050-2004
7705-1120-2004
