GFA-5400 SERVICE PARTS LIST
Power Supply PCB
AF608615
SCHEMATIC ADCOM PART NUMBER
LOCATION
C901-C904 12005565
C905-C908 12001185
C909-C912 12005420
C913-C916 12005195
C917-C920 12001185
D903-D914 16004003
R901-R904 27001590
R905-R912 27005030
R913-R916 27003280
TH901, TH902 31000512
Amplifier PCB
AF608625, AF608635
SCHEMATIC ADCOM PART NUMBER
LOCATION
C601,C602 12003175
C603,C604 12001260
C605,C606 12005470
C607,C608 12001020
C609,C610 12005325
C611,C612 12005280
C613,C614 12001410
C615,C616 12001285
C617,C618 12001420
C711,C712 12005090
C713,C714 12002070
C715,C716 12005040
C717,C718 12005080
D601-D604 16000082
D607-D616 16000082
D711,D712 16004003
F601-F604 19000500
IC711, IC712 21005550
Q601-Q604 33002100
Q605,Q606 33000610
Q607,Q608 33009210
Coupling
R675 R675
R676 R676
L SPKR -
R SPKR -
Adjust
VR603
VR604
VR601
VR602
DESCRIPTION
CAPACITOR ELECTROLYTIC 12000uF 63V
CAPACITOR MP
CAPACITOR ELECTROLYTIC 1000uF 16V
CAPACITOR ELECTROLYTIC 470uF 100V
CAPACITOR MP
DIODE
RESISTOR
RESISTOR ROED.
RESISTOR ROED.
THERMISTOR
DESCRIPTION
CAPACITOR STYROL
CAPACITOR MP
CAPACITOR ELECTROLYTIC 47uF 100V
CAPACITOR LAYER
CAPACITOR ELECTROLYTIC 4.7uF 50V
CAPACITOR ELECTROLYTIC 47uF 50V
CAPACITOR STYROL
CAPACITOR MYLAR
CAPACITOR STYROL
CAPACITOR ELECTROLYTIC 10uF 25V
CAPACITOR CERAMIC
CAPACITOR ELECTROLYTIC 22uF 50V
CAPACITOR ELECTROLYTIC 100uF 16V
DIODE
DIODE
DIODE
FUSE
TIMER IC
TRANSISTOR
TRANSISTOR
TRANSISTOR
2
Adjust For
DC Voltmeter
reads 35mV
DC Voltmeter
reads 0mV
0.1uF 250V
0.1uF 250V
1N4003
5.6K 1W MOF
10 1/2W FUSABLE
8.2K 2W 5% METAL
SCK0512
390pF 125V
2.2uF 100V
1uF 50V
47pF 125V
0.1uF 100V
22pF 125V
0.01uF 50V
RD8.2JS-T1
RD8.2JS-T1
1N4003
5A 250V
NJM555D
IRFD210
IRF610
IRFD9210
