Adcom GTP-740 Service Manual page 8

PARTS LIST
REF NO.
RESISTOR
R401,R403,R405,R407,R409,R411,R413,R415,
R417,R419,R422,R428,R429,R431,R432,R434,
R435,R437,R438,R711,R716,R723
R423,R441,R442,R445,R451,R457,R459,R460,
R462,R468,R472,R474,R475,R479,R486,R488,
R490,R491,R499,R722,R724,R727,R729,R733,
R734,R735,R756-R767
R731
R443,R465,R481,R495
R710,R715,R725,R730,R776,R777
R402,R404,R406,R408,R410,R412,R414,R416,
R418,R420
R741
R448,R454,R732
R449,R455,R456,R458,R470,R471,R473,R477,
R487,R489,R493,R702,R704,R706,R713,R718,
R751,R768-R773,R778-R781
R421,R424,R427,R430,R433,R436,R439,R440,
R444,R450,R461,R466,R478,R484,R497,R707,
R721
R467,R485,R498
R742-R747
R425,R712,R717,R749,R753,R754
R720,R748,R750,R804
R447,R453,R469,R476,R492,R701,R703,R705
R464,R482,R496
R463,R480,R494
R752
R446,R452
J713-J715,J718,J721-J723
R782
R714,R719
DIODE
D401,D403
D409,D410
J487/
D404,D407
D408
TRANSISTOR
Q403-Q405,Q407-Q414
Q406,Q415,Q416
Q402
Q401
HEATSINK
U426
U427
DESCRIPTION
RMF 1/8W 1K 1% AT
RMF 1/8W 10K 1% ATS
RMF 100K 1/8W 1% AT
RMF 1/8W 100K 1% ATS
RMF 1/8W 12K 1% AT
RMF 1/8W 20K 1% AT
RMF 1/8W 22R 1% ATS
RMF 1/8W 2.2K 1% ATS
RMF 1/8W 22K 1% AT
RMF 1/8W 220K 1% AT
RMF 1/8W 3.9K 1% AT
RMF 1/8W 470R 1% ATS
RMF 1/8W 4.7K 1% ATS
RMF 1/8W 47K 1% ATS
RMF 1/8W 560R 1% ATS
RMF 1/8W 56K 1% AT
RMF 1/8W 68K 1% AT
RMF 1/8W 7.5K 1% AT
RMF 1/8W 91K 1% AT
RMF 1/4W 1R 1% AT
RMF 1/4W 220R 1% AT
RMF 1/2W 120R 1% AT
DIODE 1N4001 AT
DIODE 1N4148 AT
DIODE 1N4148 ATS
DZ 1/2W 9.94~10.44V ROHM
DZ 1/2W 3.16~3.38V ROHM
TR SS8050 C/D SAMSUNG RL
TR SS8550 C/D SAMSUNG RL
TR 2SA1015 (G.R.) RL
TR 2SC1815 (G.R) RL
HEATSINK 23.5X17X35
HEATSINK 23.5X17X50
8
GTP-740
PART NO.
4711-102A-2
4711-103A-C
4711-104A-2
4711-104A-C
4711-123A-2
4711-203A-2
4711-220A-C
4711-222A-C
4711-223A-2
4711-224A-2
4711-392A-2
4711-471A-C
4711-472A-C
4711-473A-C
4711-561A-C
4711-563A-2
4711-683A-2
4711-752A-2
4711-913A-2
4715-010A-2
4715-221A-2
4717-121A-2
4804-0010-2
4804-1480-2
4804-1480-C
4837-10D1-2
4837-3A31-2
4860-0050-5
4860-0060-5
4860-0660-5
4860-0700-5
5400-1611-0
5400-1702-0
