Adcom GTP-740 Service Manual page 13

PARTS LIST
REF NO.
RESISTOR
R641
R638
R633,R634
R374,R612,R615,R639,R642,U322/U
R375
R624
R378,R379
R376
R635,R636
R355,R622
R621
R357
R369
R356
R617
R616
R614,R620
R381
R382,R632
R354,R392,R619,R640
R637
R618
R370
R611,R613
R368,R393
R380
R623
R361-R367,R394
R385
R371
R386
R372,R373,R377
DIODE
D309,D310,D311,D312
D308
TRANSISTOR
Q316,Q317
Q313
Q304,Q305,Q307,Q310,Q312,Q314
MISCELLANEOUS
J730
M301
VOL ASSY
PC BOARD
1400
DESCRIPTION
RMF 1/8W 100R 1% AT
RMF 1/8W 1K 1% AT
RMF 1/8W 10K 1% AT
RMF 1/8W 10K 1% ATS
RMF 1/8W 100K 1% ATS
RMF 1/8W 130K 1% AT
RMF 1/8W 150R 1% ATS
RMF 1/8W 1.5K 1% AT
RMF 1/8W 2K 1% AT
RMF 1/8W 20K 1% AT
RMF 1/8W 220R 1% AT
RMF 1/8W 2.2K 1% AT
RMF 1/8W 2.2K 1% ATS
RMF 1/8W 22K 1% AT
RMF 1/8W 2.7K 1% AT
RMF 1/8W 30K 1% AT
RMF 1/8W 330R 1% ATS
RMF 1/8W 33K 1% AT
RMF 39K 1/8W 1% AT
RMF 1/8W 470R 1% ATS
RMF 1/8W 4.7K 1% AT
RMF 1/8W 4.7K 1% ATS
RMF 1/8W 47K 1% ATS
RMF 1/8W 470K 1% AT
RMF 1/8W 68R 1% AT
RMF 1/8W 6.8K 1% AT
RMF 1/8W 68K 1% AT
RMF 1/8W 75R 1% ATS
RMF 1/4W 100R 1% AT
RMF 1/4W 150R 1% AT
RMF 1/4W 510R 1% AT
RMF 1/2W 10R 5% AL
DIODE 1N4148 AT
DZ 1/2W 12.2-12.7V AT
TR 2SD1012F/G HFE
TR 2SA1015-Y HFE120-240
TR 2SC930E HFE 100-200
TERMINAL PIN
BRACKET, GROUNDING
VOL PCB ASSY A0150C
13
GTP-740
PART NO.
4711-101A-2
4711-102A-2
4711-103A-2
4711-103A-C
4711-104A-C
4711-134A-2
4711-151A-C
4711-152A-2
4711-202A-2
4711-203A-2
4711-221A-2
4711-222A-2
4711-222A-C
4711-223A-2
4711-272A-2
4711-303A-2
4711-331A-C
4711-333A-2
4711-393A-2
4711-471A-C
4711-472A-2
4711-472A-C
4711-473A-C
4711-474A-2
4711-680A-2
4711-682A-2
4711-683A-2
4711-750A-C
4715-101A-2
4715-151A-2
4715-511A-2
4717-100J-1-P
4804-1480-2
4837-9A30-2
4851-012F-5
4851-015Y-5
485C-930E-5
4132-1071-0
4132-6221-0
PCB-A0150C-VOL
