Adcom GTP-740 Service Manual page 19

PARTS LIST
REF NO.
RESISTOR
R3,R4
R1,R2,R11-R14,R17-R19,
R21
R10,R5,R6,R7,R8,R9
DIODE
D1
TRANSISTOR
Q1
SWITCH
S1
HEATSINK
0001
MISCELLANEOUS
0002
POWER ASSY
PC BOARD
1100
PCB
CAPACITOR
C802,C806,C807,C809,C810,C813,C814,C816,C818,
C820,C822,C824,C825,C827,C829,C830,C834
C832
C826,C831
C823
C821,C828
C815
C812
C803
C804
C805
C811
C808,C817
C801,C819
TRANSFORMER
L801
L802
WAFER
J808,J809
DESCRIPTION
RCFA 1/8W 20K 5% RL 9
RMG 1/10W 22K 5% 0805
RMG 1/10W 330R 5% 0805
RMG 1/10W 47R 5% 0805
DUAL DIODE KDS226 KEC
TR 2SC2814 HFE 90-180
SW 4 POLES DIP
HEATSINK IC ANODISED
HEX STANDOFF M3X11
POWER PCB ASSY A0153C
PCB PSU/JACK A0160C
CC 50V 0.1uF 10% RL 5x5
CE 16V 1000uF 20% RL
CE 16V 470uF 20% RL
CE 25V 1000uF 20% RL
CE 25V 2200UF 20% RL
CE 25V 470uF +80/-20% RL
CE 50V 1000uF 20% RL
CE 50V 220uF 20% RL
CE 50V 330uF 20% RL
CE 35V 220uF 20% RL
CE 35V 2200uF 20% RL
CE 3300UF 50V 20% RL
CAP400V 4700P
TRANSFORMER GTP-750
EI-35 TRANSFORMER GTP750
4 PIN HEADER W/HOOK JST
19
GTP-740
PART NO.
4701-203J-5-09
4720-223J-J
4720-331J-J
4720-470J-J
480S-2260-3
4852-8144-3
5200-4711-0
5400-4071-0
4132-7131-0
PCB-A0153C-PWR
1724-090A-0102
150F-104K-5-II
157D-108M-5-S5
157D-477M-5-SY
157E-108M-5-X&
157E-228M-5-X&K
157E-477Z-5-S5
157F-108M-5-W9
157F-227M-5-S5
157F-337M-5-S9
157Q-227M-5-OV
157Q-228M-5-5&
8910-0008-0
8910-0049-0
1806-2319-1
1806-2501-0
2101-1981-0
