Adcom GTP-740 Service Manual page 11

PARTS LIST
REF NO.
R335,R336,R384
R322
R326
R319,R331
R315
R325,R349
R359
R348,R383
R318,R321,R333
R360
R320
R327
R328
R358,R627
R630
R399
R329,R351
R340,R343,R346,R628,R629
R339
R631
R323
R390,R391
R330
R301-R314,R388,R389
R342,R345
R344,R347
IC
U306
U305
U302,U304,U310-U313
U301,U303
U307,U308,U309
SVR
R334
DIODE
D301-D307
J378
TRANSISTOR
Q308
Q301-Q303,Q306,Q309,Q311
SWITCH
M311
MISCELLANEOUS
J374,J375
DESCRIPTION
RMF 1/8W 100K 1% ATS
RMF 1/8W 1M 1% ATS
RMF 1/8W 1.2K 1% ATS
RMF 1/8W 12K 1% AT
RMF 1/8W 180R 1% AT
RMF 1/8W 2K 1% AT
RMF 1/8W 20K 1% AT
RMF 1/8W 2.2K 1% AT
RMF 1/8W 2.2K 1% ATS
RMF 1/8W 22K 1% AT
RMF 1/8W 30K 1% AT
RMF 1/8W 3.3K 1% AT
RMF 1/8W 3.9K 1% AT
RMF 1/8W 47R 1% AT
RMF 1/8W 470R 1% ATS
RMF 1/8W 4.7K 1% AT
RMF 1/8W 4.7K 1% ATS
RMF 1/8W 47K 1% ATS
RMF 1/8W 5K 1% AT
RMF 1/8W 56R 1% AT
RMF 1/8W 560R 1% ATS
RMF 1/8W 68R 1% AT
RMF 1/8W 6.8K 1% AT
RMF 1/8W 75R 1% ATS
RMF 1/8W 7.5K 1% AT
RMF 1/4W 150R 1% AT
IC NJM2217 VIDEO
IC PCA8515P/009 OSD
IC BA7612N VIDEO SIGNAL
IC BA7645N VIDEO SIGNAL
IC BA7602 VIDEO SW.3X2CH
SVR 47K H3 10X10
DIODE 1N4148 AT
DZ 1/2W 3.16~3.38V ROHM
TR 2SA1015-Y HFE120-240
TR 2SC930E HFE 100-200
DPDT SLIDE
SOLDER TAG
11
GTP-740
PART NO.
4711-104A-C
4711-105A-C
4711-122A-C
4711-123A-2
4711-181A-2
4711-202A-2
4711-203A-2
4711-222A-2
4711-222A-C
4711-223A-2
4711-303A-2
4711-332A-2
4711-392A-2
4711-470A-2
4711-471A-C
4711-472A-2
4711-472A-C
4711-473A-C
4711-502A-2
4711-560A-2
4711-561A-C
4711-680A-2
4711-682A-2
4711-750A-C
4711-752A-2
4715-151A-2
3130-3760-0
3130-4130-0
3130-6290-0
3130-6300-0
3130-6450-0
4756-4730-3-11
4804-1480-2
4837-3A31-2
4851-015Y-5
485C-930E-5
5200-3171-0-01
4132-1061-0
