Adcom GTP-740 Service Manual page 10

PARTS LIST
REF NO.
PCB
1801
WAFER
J491
JACK
J490
S.VIDEO ASSY
PC BOARD
1300
PCB
1301
CAPACITOR
C343
C316,C319,C328,C331,C335,C341,C352,C354,C385
C339,C340
C348
C342
C349
C324,C359,C360,C381,C388
C329,C355
C358
C386
C336
C338
C301-C315,C317,C318,C320-C323,C325-C327,
C330,C332-C334,C337,C345-C347,C350,C351,
C353,C356,C357
C344
WAFER
J316
J321
J346
J326
CONNECTOR
J701-J712
CRYSTAL
M325
RESISTOR
R341,R626
R316,R317,R324,R332,R337,R338,R350,R352,
R353,R387,R395-R398
DESCRIPTION
PCB AUDIO/PSU/JACK
4P ST.WAFER
PHONE JACK
S.VIDEO PCB ASSY A0150C
PCB VIDEO/S-VIDEO/VOL
CC 25V 0.068uF 10% RL 8x
CC 50V 0.1uF 10% RL 5x5
CC 50V 22pF 5% RL 5x3.5
CC 50V 560pF 10% RL 4x4
CC 50V 680pF 10% RL 4x4
CM 50V 1000pF 10% RL 6x1
CE 10V 100uF 20% RL 5x11
CE 10V 470UF 20% RL 8X11
CE 16V 100uF 20% RL 5x11
CE 16V 33uF 20% RL 5x11
CE 25V 3.3uF 20% RL 4x7
CE 50V 1uF 20% RL 4x7
CE 50V 10uF 20% RL 4x7
CE 50V 2.2uF 20% RL 4x7
WAFER 2P P2.5 RIGHT
4P ST.WAFER
WAFER 7P P2.5 RIGHT
WAFER 9P P2.5 RIGHT
1P DIN CONNECTOR HDC-050
X'TAL 3.58MHZ HC-49/U
RMF 1/8W 1K 1% AT
RMF 1/8W 10K 1% ATS
10
GTP-740
PART NO.
1722-780A-0101
2102-041S-004
2113-1011-0
PCB-A0150C-SVDO
1722-790A-0102
150E-683K-5-OG
150F-104K-5-II
150F-220J-5-IF
150F-561K-5-GG
150F-681K-5-GG
153F-102K-5-KW
157C-107M-5-IU
157C-477M-5-OU
157D-107M-5-IU
157D-336M-5-IU
157E-335M-5-GM
157F-105M-5-GM
157F-106M-5-GM
157F-225M-5-GM
2102-021R-004
2102-041S-004
2102-071R-004
2102-091R-004
2113-1183-0
2300-0930-0
4711-102A-2
4711-103A-C
