Adcom GTP-740 Service Manual page 17

PARTS LIST
REF NO.
U202
U204
U201
RESISTOR
R280
R278,R279
R208
R221,R229
R207,R210,R233,R244-R248,R253,R254,R262,R264
R204,R231,R232,R255
R257
R219,R227
R241,R277
R209
R265,R266
R239
R202,R236,R237
R222,R230,R243,R259
R212,R256
R206
R234,R242,R269,R271
R238
R215,R216,R223,R224
R240,R260
R261
R213
R211
R201
R267,R268
R203,R205,R275,R276
R220,R228
R235
R214,R217,R225
R270,R272
R218,R226
R273,R274
SVR
R263
DIODE
D201,D202
D205
D203,D204
TRANSISTOR
Q204-Q208
Q209,Q213
Q201-Q203,Q210-Q212
DESCRIPTION
IC LA1266 FM/AM TUNER
IC LA3401 PLL MPX
IC LM7000 DTS SANYO
RMF 1/8W 10K 1% ATS
RMF 1/8W 2.7K 1% AT
RMF 1/4W 100R 1% AT
RMF 1/4W 1K 1% AT
RMF 1/4W 10K 1% AT
RMF 1/4W 100K 1% AT
RMF 1/4W 1.2K 1% AT
RMF 1/4W 1.5K 1% AT
RMF 1/4W 15K 1% AT
RMF 1/4W 150K 1% AT
RMF 1/4W 180K 1% AT
RMF 1/4W 20R 1% AT
RMF 1/4W 20K 1% AT
RMF 1/4W 22R 1% AT
RMF 1/4W 220R 1% AT
RMF 1/4W 2.2K 1% AT
RMF 1/4W 2.7K 1% AT
RMF 1/4W 30K 1% AT
RMF 1/4W 330R 1% AT
RMF 1/4W 3.3K 1% AT
RMF 1/4W 33k 1% AT
RMF 1/4W 39R 1% AT
RMF 1/4W 390R 1% AT
RMF 1/4W 39K 1% AT
RMF 1/4W 390K 1% AT
RMF 1/4W 4.7K 1% AT
RMF 1/4W 510R 1% AT
RMF 1/4W 5.1K 1% AT
RMF 1/4W 680R 1% AT
RMF 1/4W 6.8K 1% AT
RMF 1/4W 75R 1% AT
RMF 1/4W 820R 1% AT
SVR 47K H3 10X10
GERMANIUM DIODE 1N60P AL
DIODE 1N4148 ATS
SVC321-D AM CAR. DIODE
TR 2SC930E HFE 100-200
TR 2SA1015 (G.R.) RL
TR 2SC1815 (G.R) RL
17
GTP-740
PART NO.
3130-3390-0
3130-3400-0
3130-3430-0
4711-103A-C
4711-272A-2
4715-101A-2
4715-102A-2
4715-103A-2
4715-104A-2
4715-122A-2
4715-152A-2
4715-153A-2
4715-154A-2
4715-184A-2
4715-200A-2
4715-203A-2
4715-220A-2
4715-221A-2
4715-222A-2
4715-272A-2
4715-303A-2
4715-331A-2
4715-332A-2
4715-333A-2
4715-390A-2
4715-391A-2
4715-393A-2
4715-394A-2
4715-472A-2
4715-511A-2
4715-512A-2
4715-681A-2
4715-682A-2
4715-750A-2
4715-821A-2
4756-4730-3-11
4801-N60P-1
4804-1480-C
484C-321D-5
485C-930E-5
4860-0660-5
4860-0700-5
