Adcom GTP-740 Service Manual page 12

PARTS LIST
REF NO.
VIDEO ASSY
PC BOARD
1200
PCB
1201
CAPACITOR
C628
C616,C617
C372,C376,C379,C620,C629
C611
C614
C623,C624
C369,C382,C387,C390,C627
C389
C383,C613,C619,C631
C368,C370
C384
C612,C615,C626
C361-C367,C371,C373-C375,C377,C378,C380
C625
C618
C621,C622
C632
WAFER
J348
J726
J388
J347
JACK/CONNECTOR
J725
J713-J719
J717,J720,J721
J722,J723,j724,J728
COIL
L301
CRYSTAL
M326
IC
U318,U319
U315,U316,U317
U314
U321
U323
U322
DESCRIPTION
VIDEO PCB ASSY A0150C
PCB VIDEO/S-VIDEO/VOL
CC 50V 100pF 10% RL 5x3.
CC 50V 1000pF 10% RL 5x5
CC 50V 0.1uF 10% RL 5x5
CC 50V 2200pF 10% RL 6.5
CC 50V 0.022uF +80/-20%
CC 50V 47pF 5% RL 5x3.5
CE 10V 100uF 20% RL 5x11
CE 10V 330uF 20% RL 8x12
CE 10V 47uF 20% RL 5x11
CE 10V 470UF 20% RL 8X11
CE 16V 10uF 20% RL 4x7
CE 50V 1uF 20% RL 5x11
CE 50V 10uF 20% RL 4x7
CE 50V 2.2uF 20% RL 5x11
CE 50V 3.3uF 20% RL 5x11
CTC 0/60 39pF 5% RL
CTC 0/60 56pF 5% RL 6x4
WAFER 3P P2.5 RIGHT
WAFER 4P P2.5 RIGHT
WF T8 DE 7PIN COULOMB
WAFER 9P P2.5 RIGHT
DIN CONNECTOR 5 PIN
1P RCA JACK YL AU
2P RCA JACK YL/YL AU
PHONE JACK D3.5 BK
FERRITE COIL 22UH BL8.5
X'TAL 14.318MHZ +/-30PPM
IC 4094 8-BIT SIPO SR 3S
IC BA7612N VIDEO SIGNAL
IC BA7645N VIDEO SIGNAL
IC BA7046F VIDEO SIGNAL
IC BU2762AL NTSC/PAL
IC NJM2220S VIDEO
12
GTP-740
PART NO.
PCB-A0150C-VDO
1722-790A-0102
150F-101K-5-IF
150F-102K-5-II
150F-104K-5-II
150F-222K-5-LF
150F-223Z-5-UG
150F-470J-5-IF
157C-107M-5-IU
157C-337M-5-OW
157C-476M-5-IU
157C-477M-5-OU
157D-106M-5-GM
157F-105M-5-IU
157F-106M-5-GM
157F-225M-5-IU
157F-335M-5-IU
15CH-390J-5-IG
15CH-560J-5-KG
2102-031R-004
2102-041R-004
2102-071S-004
2102-091R-004
2113-1168-0
2113-1170-0
2113-1171-0
2113-1179-0
1807-220J-P
2300-2680-0
3130-3600-0
3130-6290-0
3130-6300-0
3130-9070-0
3130-9080-0
3130-9090-0
