Adcom GTP-740 Service Manual page 14

PARTS LIST
REF NO.
PCB
1401
CAPACITOR
C602,C603
C601,C605,C606
WAFER
J602
J601
IC
U601
VR
R601
KEYBOARD ASSY
PC BOARD
1500
PCB
1505
CAPACITOR
C502
C501
C503,C505,C511,C513,C515,C517,C519,C521
C507
C504,C512,C514,C516,C518,C520,C522
C523
C506
C508
COIL
L502
TRANSFORMER
L501
IC
U508
U502-U507
U501
LED
D512-D515,D517-D532
D501-D511,D516
DESCRIPTION
PCB VIDEO/S-VIDEO/VOL
CC 50V 0.1uF 10% RL 5x5
CE 16V 10uF 20% RL 4x7
3 PIN ST. WAFER
WAFER 5 PIN P2.5
IC LB1642 MOTOR DRIVER
VR RK16312MCL 50K
KEYBOARD PCB ASSY A0151C
PCB KEYBOARD
CC 25V 0.033uF 20% RL
CC 50V 0.01uF 10% RL 5x5
CC 50V 0.1uF 10% RL 5x5
CM 50V 0.01u 5% RL 5X7
CE 16V 10uF 20% RL 4x7
CE 16V 100uF 20% RL 5x11
CE 16V 47uF 20% RL 5x11
CE 50V 0.47uF 20% RL 4x7
COIL 100UH 10%
TRANSFORMER STEP-UP 5V
IC NJM78L05A 826
IC 4094 8-BIT SIPO SR 3S
IC MSM9006-02 LCD DRIVER
LED SP 3X5.5 L0.5 RD
LED RT 5X2X7MM RED
14
GTP-740
PART NO.
1722-790A-0102
150F-104K-5-II
157D-106M-5-GM
2102-031S-004
2102-051R-004
3130-3410-0
4750-6196-0
PCB-A0151C-KEY
1722-900A-0002
150E-333M-5-OG
150F-103K-5-II
150F-104K-5-II
153F-103J-5-IM
157D-106M-5-GM
157D-107M-5-IU
157D-476M-5-IU
157F-474M-5-GM
1801-101K-M
1806-2320-0
3130-0640-0
3130-3600-0
3130-6350-0
3700-2380-R
3700-5577-R
