Adcom GTP-740 Service Manual page 18

PARTS LIST
REF NO.
RF COIL
L211,L212
L207
L208
L209
L206
L205
L210
MISCELLANEOUS
M207
J202(1)/GND,TUN
M211,M212,M213,M214
ANT.,COP. SIDE
DTS ASSY
PC BOARD
1900
PCB
0000
CAPACITOR
C1,C3,C6-C12,C14,C18-C20,
C2
C13,C15,C16,C17
WAFERS/SOCKET/CONNECTOR
J2,J4
J1,J3
0006
CRYSTAL
OSC1
SCREW
1111
IC
U101
U1
U3
U4
U5
U6
U2
LED
D2
DESCRIPTION
19KHZ FILTER COIL
AMZFT COIL (5565105200)
FM COIL PRIMARY
FM COIL SECONDARY
AM COIL 5564102600
AM OSC COIL 5564312800
AM OSC COIL
CR RESONATOR
SOLDER TAG
TERMINAL PIN
RF COAXIAL WIRE 100MM
PCB ASSY DTS A0152C
PCB DTS A0152C
CC 50V 0.1uF 20% 0805 1.
CE 10V 47uF 20% RL 5x11
CE 16V 10uF 20% RL 4x7
10 PIN P2.54 CONNECTOR
WAFER 10PIN P2.54 DUAL
32 PIN DIP IC SOCKET
X'TAL 1.000MHZ CCO-21S
SCREW M3X6
IC M51943A SYSTEM RESET
IC MC56009/88 DTS
IC KM68257C-15 32KX8
IC HC373
IC 74HC14 SOP PACKAGE
IC 74HC4053M SOP PACKAGE
IC AM27C010-150DC EEPROM
LED RT 5X2X7MM RED
18
GTP-740
PART NO.
5600-2236-S
5600-2246-S
5600-2256-S
5600-2266-S
5600-2276-S
5600-2286-S
5600-2296-S
2703-0020-0
4132-1061-0
4132-1071-0
8612-1000-0
PCB-A0152C-DTS
1724-320A-0000
150F-104M-J-BD
157C-476M-5-IU
157D-106M-5-GM
2101-0821-0
2101-0831-0
2101-1971-0
2300-3000-0
2904-3006-0000
3130-5860-0
3130-8600-0
3130-8610-0
3130-8630-0
3130-8680-0
3130-8700-0
3130-9250-0
3700-5577-R
