Adcom GTP-740 Service Manual page 16

PARTS LIST
REF NO.
C245/CHA,C263,C265
C203,C204,C213-C219,C226,C245,J202(1)/GND
C210,C244,C264
C211,C222
C267
C236
C223
C261,C262
C212,C220
C209
C230,C243,C255,C256,C259,C260
C242,C246
C253
C254
C247,C249,C250
C208
C248
C207,C232,C239
C201
C231
C205
C240
C257,C258
C252
COIL
l201,l203
l204
TRANSFORMER
L213
WAFER
J204
J202
J201
CONNECTOR/TERMINAL
J205
J206
CRYSTAL
M206
CERAMIC FILTER
M205
M202,M203,M204
L202
IC
U205
DESCRIPTION
CC 50V 0.01uF 10% RL 5x5
CC 50V 0.01uF 10% RL 11x
CC 50V 0.1uF 10% RL 5x5
CC 50V 22pF 10% RL 4x4
CC 50V 33pF 5% RL 4x4
CC 50V 47pF 5% RL 5x3.5
CC 50V 470pF 10% RL 9.5x
CM 50V 1500pF 5% RL 6x12
TRIMCAP 5.2-30P
CE 6.3V 100uF 20% RL 6x7
CE 16V 10uF 20% RL 5x11
CE 16V 100uF 20% RL 6x12
CE 16V 47uF 20% RL 5x11
CE 50V 0.1uF 20% RL 5x11
CE 50V 1uF 20% RL 5x11
CE 50V 100uF 20% RL 8x12
CE 50V 0.22uF 20% RL
CE 50V 3.3uF 20% RL 5x11
CE 50V 0.47uF 20% RL
CE 50V 4.7uF 20% RL 5x11
CE 35V 0.47uF 20% RL
CP 50V 100pF 5% RL 6x12
CP 50V 270pF 5% RL 6X12
CP 50V 390pF 5% RL 6x12
COIL 2.2UH 20% AL BL7
COIL 68UH 20% BL7
BALUN TRANSFORMER 300 TO
3 PIN ST. WAFER
5P ST.WAFER
9-PIN WAFER
PUSH TERMINAL 4P
DIN CONNECTOR FOR ANT
CRYSTAL 7.2MHZ 20PPM
CF 450.5+-1 SFZ450G3LI
CF 10.7MHZ SFELA10M7JAXE
BAND PASS FILTER
IC NJM78L05A 826
16
GTP-740
PART NO.
150F-103K-5-II
150F-103K-5-UU
150F-104K-5-II
150F-220K-5-GG
150F-330J-5-GG
150F-470J-5-IF
150F-471K-5-RG
153F-152J-5-KW
1551-0210-0
157B-107M-5-KM
157D-106M-5-IU
157D-107M-5-KW
157D-476M-5-IU
157F-104M-5-IU
157F-105M-5-IU
157F-107M-5-OW
157F-224M-5-IU
157F-335M-5-IU
157F-474M-5-IU
157F-475M-5-IU
157Q-474M-5-IU
158F-101J-5-KW
158F-271J-5-KW
158F-391J-5-KW
1801-2R2M-M
1801-680M-M
1806-2201-0
2102-031S-004
2102-051S-004
2102-091S-004
2113-1175-0
2113-1191-0
2300-0440-0
2701-0066-0
2701-0556-1-0
2701-0609-4
3130-0640-0
