Operating Guide | VLT® HVAC Drive FC 102
FC 102
Output current (3-phase)
Continuous (at 550 V) [A]
Intermittent (60 s overload) (at 550 V) [A]
Continuous (at 575/690 V) [A]
Intermittent (60 s overload) (at 575/690
V) [A]
Continuous kVA (at 550 V) [kVA]
Continuous kVA (at 575 V) [kVA]
Continuous kVA (at 690 V) [kVA]
Maximum input current
Continuous (at 525 V) [A]
Continuous (at 575/690 V) [A]
Maximum number and size of cables per phase
2
- Mains [mm (AWG)]
- Mains with disconnect [mm
- Mains with fusible disconnect [mm
(AWG)]
- Mains with contactor [mm
2
- Motor [mm (AWG)]
Drive module power loss at 600 V [W]
(2) (3)
Drive module power loss at 690 V [W]
(2) (3)
Drive efficiency (2)
Output frequency [Hz] (4)
Heat sink overtemperature trip [°C (°F)]
Control card overtemperature trip [°C
(°F)]
PHF overtemperature trip [°C (°F)]
dU/dt filter overtemperature trip [°C (°F)]
Sine-wave filter overtemperature trip [°C
(°F)]
1
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These values are based on a typical motor
efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the drive. Applies to dimensioning of drive cooling. If the switching frequency is higher than the default
162 | Danfoss A/S © 2018.10
N500
523
575
500
550
498
498
598
504
482
4x120 (4x250
mcm)
4x120 (4x250
2
(AWG)]
mcm)
4x120 (4x250
2
mcm)
4x120 (4x250
2
(AWG)]
mcm)
4x120 (4x250
mcm)
6879
(1)
6715
(1)
0.98
0–590
110 (230)
80 (176)
150 (302)
150 (302)
150 (302)
N560 N630
596 630
656 693
570 630
627 693
568 600
568 627
681 753
568 607
681 607
4x120 (4x250 4x185 (4x350
mcm) mcm)
4x120 (4x250 4x185 (4x350
mcm) mcm)
4x120 (4x250 4x185 (4x350
mcm) mcm)
4x120 (4x250 4x185 (4x350
mcm) mcm)
4x120 (4x250 4x185 (4x350
mcm) mcm)
8076 9208
7852 8921
0.98 0.98
0–590 0–590
110 (230) 110 (230)
80 (176) 80 (176)
150 (302) 150 (302)
150 (302) 150 (302)
150 (302) 150 (302)
Specifications
N710 N800
763 889
839 978
730 850
803 935
727 847
727 847
872 1016
735 857
704 819
4x185 (4x350 4x185 (4x350
mcm) mcm)
4x185 (4x350 4x185 (4x350
mcm) mcm)
4x185 (4x350 4x185 (4x350
mcm) mcm)
4x185 (4x350 4x185 (4x350
mcm) mcm)
4x185 (4x350 4x185 (4x350
mcm) mcm)
10346 12723
10066 12321
0.98 0.98
0–590 0–590
110 (230) 110 (230)
80 (176) 80 (176)
150 (302) 150 (302)
150 (302) 150 (302)
150 (302) 150 (302)
AQ262141314214en-000101 / 130R0880
