- Page 1 WSP-MC350 MODEL (3inch Mobile Printer) Rev. 1.0 http://www.woosim.com...
- Page 2 Copyright ⓒ2018 by Woosim Systems Inc. All rights reserved. The information contained in this manual is the property of Woosim Systems Inc. And may not be reproduced in whole or in part without the prior written permission of Woosim Systems Inc.
- Page 3 WSP-MC350 Rev. 1.0 Introduction The WSP-MC350 is the ideal solution for Mobile banking system , Retail, point of sales, Credit card Transaction, other traveling and mobile computing etc. The general features of WSP-MC350 printer are as follows: Compact size (114.1 X 143.0 X 55.4mm) ...
- Page 4 WSP-MC350 Rev. 1.0 Operating Precautions Please follow the precautions below to enjoy and maintain the full performance of the printer. Using the Printer ● Be careful not to drop or bump the printer on a hard surface. ●...
-
Page 5: Table Of Contents
WSP-MC350 Rev. 1.0 CONTENTS 1. Outline ................................. 7 1.1. Model classifications ..........................7 1.2 Symbol ................................7 1.3. Product Part Number System ........................8 1.4. Specifications............................... 9 2. Setting up the printer ............................11 2.1. Printer & Accessories ..........................11 2.2. - Page 6 WSP-MC350 Rev. 1.0 6.1. Recommended paper ..........................28 6.2. Printing position ............................28 7. Revision History ..............................29 http://www.woosim.com...
-
Page 7: Outline
WSP-MC350 Rev. 1.0 WSP-MC350 Model Interface C1 : USB/Bluetooth Power None : DC 8.4V Standby symbol IEC 5009, the standby symbol(line partially within a broken circle), Indicates a sleep mode or low power state. Direct current symbol This symbol is found on many electronic devices that either require or produce direct current. -
Page 8: Product Part Number System
WSP-MC350 Rev. 1.0 Model name Interface Spec. Wired Wireless RS-232C Bluetooth SC30 IrDA None RS-485 Parallel None Example) 1. Porti-S40 UART/Bluetooth Part No. ⇒ S40/A1 2. Porti-SC30 Bluetooth Only Part No. ⇒ SC30/Z1 Note) The above table is the interface format which is supported. -
Page 9: Specifications
WSP-MC350 Rev. 1.0 Item Specification Printing method Direct thermal line printing - Font Size A: 12X24 / Font Size B : 9X24 / Font Size C : 8X16 Character size - KOR : 24X24(16X24) / CHN, JPN : 24X24 - Font A : 48cpl / Font B : 64cpl / Font C : 72cpl... - Page 10 WSP-MC350 Rev. 1.0 Item Specification (Continue…) Battery Rechargeable 7.4V DC, 1800mAh (Li-ion) Battery duration 1 hour continuous printing Input (100~240V AC 50~60Hz) Battery Charger Output(8.4VDC/0.8A), 4hours full charge time -10°C ~ 50°C (operating) Temperature -10°C ~ 70°C (storage) Environment Conditions...
-
Page 11: Setting Up The Printer
WSP-MC350 Rev. 1.0 & & Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. Thermal roll paper Belt Clip Battery Pack WSP-MC350 Communication cable Battery charger adaptor ▼ OPTIONAL... -
Page 12: Printer Features
WSP-MC350 Rev. 1.0 ▶ Part Name http://www.woosim.com... -
Page 13: Dimensions
WSP-MC350 Rev. 1.0 http://www.woosim.com... -
Page 14: Replacing The Paper Roll
WSP-MC350 Rev. 1.0 Note : Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer can not detect the paper end correctly. 1. Make sure that the printer is not receiving data; otherwise, data may be lost. -
Page 15: Power Supply
WSP-MC350 Rev. 1.0 The following specification is requested for Power supply. Battery Charger : DC 8.4V/0.8A Avoid using power supply which its power capacity of power current is extremely high. Warning : ● Before installing or removing the battery pack, ensure the printer is OFF. -
Page 16: Recharging The Battery
WSP-MC350 Rev. 1.0 For recharging the battery pack, install the battery pack in the printer. Insert the Battery Charger to the charge connector of the printer. ● While charging the printer, turn off the printer power. NOTE : ● Do not remove the battery during charging. -
Page 17: Set Operation Mode
WSP-MC350 Rev. 1.0 In keeping on pressing the Feed and Power button simultaneously until after the ERROR lamp blinks 5 times, the printer comes out at the circumstance to change the printer mode. (refer to Table 2) POWER button : use for changing OPTION status. - Page 18 WSP-MC350 Rev. 1.0 [Example] The defaults of the printer are : USB / Density Low / Mark No Use / Sensor High / PWDN 5 min slp If a user wants to modify the defaults with Bluetooth / Density High / Mark Use / Sensor Low / PWDN No Use Press FEED &...
-
Page 19: Gap/Hole Sensor Setting
WSP-MC350 Rev. 1.0 Set Mark as GAP / HOLE on mode setting. If feed button keeps being pressed during self “SENSOR SETTING” appears on LCD window and paper keeps coming out “SENSOR SETTING”. If feed button is not pressed after printing more than 3 pages of label Setting is completed as Green and Red LED flash and “COMPLETE”... -
Page 20: Memory Switch Table
WSP-MC350 Rev. 1.0 Mode Option Etc. Mode Option Etc. No use Communi- USB(Pro) 1min Sleep cation Bluetooth 2min Sleep Port Bluetooth(Pro) 3min Sleep Bluetooth(iAP) 4min Sleep Power 5min Sleep Down Density Medium 1min Off High 2min Off No use 3min Off... -
Page 21: Interface
WSP-MC350 Rev. 1.0 The WSP-MC350 printer has a USB interface and is connected by means of a 5 pin mini USB socket. In the following table, the signals present on the Mini- USB socket are listed: Pin No. Name Function DATA “-”... -
Page 22: Read A Magnetic Stripe Card
WSP-MC350 Rev. 1.0 Please take notice that magnetic stripe card should be swapped in direction of arrow. Card can be read in both. ▶ Check the direction of the magnetic stripe and read the card. ▶ Holding the card as shown above, please pass at a steady speed (check the direction of the arrow). -
Page 23: Smart Card Module
WSP-MC350 Rev. 1.0 Contact Smart Card Reader Module for ISO/IEC-7816 Support Asynchronous Protocol T=0,T=1 Smart Card Connection Short Circuit Current Limitation 6KV ESD Protection on whole Smart Card Interface Connector : Friction Type with Smart Card presence detection 1 SAM (Security Application Module) ... -
Page 24: Communication Protocol Sequence
WSP-MC350 Rev. 1.0 Host Command Module Execution Response 500ms timeout Host Command Command Command Module Command is Executio canceled Host Command Command Error Module CheckSumEr Executio http://www.woosim.com... -
Page 25: Using The Printer
WSP-MC350 Rev. 1.0 (Fig.4.1) Button FEED Button : Use feed button to feed the paper continuously. - POWER Button : This button is used to power on/off. When of 5 or more seconds presses and power comes to on or off. -
Page 26: The Self Test
3. Printer will print out the current status. (F/W version and set contents) 4. And then pattern of characters will be printed out. 5. Self-test will be finished automatically and turned to the standby status. ※ In case printer does not work properly, please contact Woosim customer service center. http://www.woosim.com... -
Page 27: Using The Accessory
WSP-MC350 Rev. 1.0 Please sling it over your shoulder after fixing the shoulder strap to the printer in the order of the illustration. Following the instruction of the arrow, please put the belt clip in the hole and turn and fix the screw to the right by using a thing like a screwdriver. -
Page 28: Consumable Parts
WSP-MC350 Rev. 1.0 Type : Thermal Paper Paper width : 80mm Paper thickness : 60±5㎛ Outer diameter : Ø50mm or less Recording side : Outside of roll Cautions 1. Do not paste the paper to the core. And the roll paper which has Near end mark printing on its near end is recommended. - Page 29 WSP-MC350 Rev. 1.0 Date Version Comments Jan. 04. 2018 Initialize http://www.woosim.com...
