All specifications are subjected to change without notice
MODEL
(3inch Mobile Printer)
Rev. 1.0
WOOSIM SYSTEMS Inc.
(#501, Daerung Technotown 3th)
115, Gasan digital 2-ro, Geumcheon-gu,
Seoul, 153-772 Rep. of KOREA
Tel : +82-2-2107-3700
Fax : +82-2-2107-3707
URL:
http://www.woosim.com
http://www.woosim.com
WSP-R341
Advertisement
Table of Contents
Related Manuals for WOOSIM WSP-R341
Summary of Contents for WOOSIM WSP-R341
- Page 1 WSP-R341 MODEL (3inch Mobile Printer) Rev. 1.0 WOOSIM SYSTEMS Inc. (#501, Daerung Technotown 3th) 115, Gasan digital 2-ro, Geumcheon-gu, Seoul, 153-772 Rep. of KOREA Tel : +82-2-2107-3700 Fax : +82-2-2107-3707 URL: http://www.woosim.com All specifications are subjected to change without notice...
- Page 2 Copyright ⓒ2015 by Woosim Systems Inc. All rights reserved. The information contained in this manual is the property of Woosim Systems Inc. And may not be reproduced in whole or in part without the prior written permission of Woosim Systems Inc.
- Page 3 WSP-R341 Rev. 1.0 Introduction The WSP-R341 is suitable designed for use with a growing variety of mobile devices. Bluetooth/USB interfaces make the WSP-R341 the perfect comrade for applications such as point of transaction warehousing, distribution, point of sales, hospitality, gaming and healthcare.
-
Page 4: Operating Precautions
WSP-R341 Rev. 1.0 Operating Precautions Please follow the precautions below to enjoy and maintain the full performance of the printer. Using the Printer ● Be careful not to drop or bump the printer on a hard surface. ●... -
Page 5: Federal Communications Commission
WSP-R341 Rev. 1.0 Federal Communications Commission Radio Frequency Interference Statement FCC ID : QDDWSP-R341 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 6: Table Of Contents
WSP-R341 Rev. 1.0 CONTENTS 1. Outline ........................... 7 1.1. Model classifications ....................7 1.2 Symbol ..........................7 1.3. Product Part Number System ..................8 1.4. Specifications......................... 9 2. Setting up the printer ....................... 11 2.1. Printer & Accessories ....................11 2.2. -
Page 7: Outline
WSP-R341 Rev. 1.0 WSP-R341 Model Interface C1 : USB/Bluetooth Power None : DC 8.4V Standby symbol IEC 5009, the standby symbol(line partially within a broken circle), Indicates a sleep mode or low power state. Direct current symbol This symbol is found on many electronic devices that either require or produce direct current. -
Page 8: Product Part Number System
WSP-R341 Rev. 1.0 Model name Interface Spec. Wired Wireless RS-232C Bluetooth SC30 IrDA None RS-485 Parallel None UART/Bluetooth Part No. ⇒ S40/A1 Example) 1. Porti-S40 2. Porti-SC30 Bluetooth Only Part No. ⇒ SC30/Z1 Note) The above table is the interface format which is supported. -
Page 9: Specifications
WSP-R341 Rev. 1.0 Item Specification Printing method Direct thermal line printing - Font Size A: 12X24 / Font Size B : 9X24 / Font Size C : 8X16 Character size - KOR : 24X24(16X24) / CHN, JPN : 24X24 - Font A : 48cpl / Font B : 64cpl / Font C : 72cpl... - Page 10 WSP-R341 Rev. 1.0 Item Specification Battery Rechargeable 7.4V DC , 1800mAh (Li-ion) Battery duration 1 hour continuous printing Input (100~240V AC 50~60Hz) Battery Charger Output(8.4VDC/0.8A), 4hours full charge time -10°C ~ 50°C (operating) Temperature -10°C ~ ”0°C (storage) Environment Conditions...
-
Page 11: Setting Up The Printer
WSP-R341 Rev. 1.0 & & Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. Battery Pack Thermal roll paper WSP-R341 A800-018 User’s Manual Battery charger adaptor ▼ OPTIONAL Communication cable Belt Clip http://www.woosim.com... -
Page 12: Printer Features
WSP-R341 Rev. 1.0 ▶ Part Name http://www.woosim.com... -
Page 13: Dimensions
WSP-R341 Rev. 1.0 None MSR http://www.woosim.com... -
Page 14: Replacing The Paper Roll
WSP-R341 Rev. 1.0 Note : Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer can not detect the paper end correctly. 1. Make sure that the printer is not receiving data; otherwise, data may be lost. -
Page 15: Power Supply
WSP-R341 Rev. 1.0 The following specification is requested for Power supply. Battery Charger : DC 8.4V/0.8A Avoid using power supply which its power capacity of power current is extremely high. ● Warning : Before installing or removing the battery pack, ensure the printer is OFF. -
Page 16: Recharging The Battery
WSP-R341 Rev. 1.0 For recharging the battery pack, install the battery pack in the printer. Insert the Battery Charger to the charge connector of the printer. ● NOTE : While charging the printer, turn off the printer power. ● Do not remove the battery during charging. -
Page 17: Set Operation Mode
WSP-R341 Rev. 1.0 In keeping on pressing the Feed and Power button simultaneously until after ERROR lamp blinks 5 times, the printer comes out at the circumstance to change the printer mode. (refer to Table 2) POWER button : use for changing OPTION status. - Page 18 WSP-R341 Rev. 1.0 [Example] The defaults of the printer are : USB / Density Low / Mark No Use / Sensor High / PWDN 5 min slp If a user wants to modify the defaults with Bluetooth / Density High / Mark Use / Sensor Low / PWDN No Use ...
-
Page 19: Gap/Hole Sensor Setting
WSP-R341 Rev. 1.0 Set Mark as GAP / HOLE on mode setting. If feed button keeps being pressed during self SENSOR SETTING appears on LCD window and paper keeps coming out SENSOR SETTING . If feed button is not pressed after printing more than 3 pages of label Setting is completed as Green and Red LED flash and COMPLETE appears on LCD window. -
Page 20: Memory Switch Table
WSP-R341 Rev. 1.0 Mode Option Etc. Mode Option Etc. No use Communi- USB(Pro) 1min Sleep cation Bluetooth 2min Sleep Port Bluetooth(Pro) 3min Sleep Bluetooth(iAP) 4min Sleep Power 5min Sleep Down Density Medium 1min Off High 2min Off No use 3min Off... -
Page 21: Interface
WSP-R341 Rev. 1.0 (Fig.3.1) The WSP-R341 printer has a USB interface and is connected by means of a 5 pin mini USB socket. In the following table, the signals present on the Mini- USB socket are listed: ① USB Pin No. -
Page 22: Bluetooth
WSP-R341 Rev. 1.0 Category Specification Bluetooth Spec. Bluetooth Ver3.0 / Class2 (10m) Frequency band 2402~2480 MHz Protocol L2CAP, RFCOMM, SDP Profile GAP, SDAP, SPP ▶ Check the direction of the magnetic stripe and swipe the card. ▶ Cards can be swiped in two ways. -
Page 23: Using The Printer
WSP-R341 Rev. 1.0 (Fig.4.1) Button FEED Button : Use feed button to feed the paper continuously. - POWER Button : This button is used to power on/off. When of 5 or more seconds presses and power comes to on or off. -
Page 24: The Self Test
(ROM version and communication mode) 4. And then pattern of characters will be printed out. 5. Self-test will be finished automatically and turned to the standby status. ※ In case printer does not work properly, please contact Woosim customer service center. http://www.woosim.com... -
Page 25: Using The Belt Clip
WSP-R341 Rev. 1.0 Following the instruction of the arrow, please put the belt clip in the hole and turn and fix the screw to the right by using a thing like a screw driver. Afterward, you can use it like the picture below... -
Page 26: Consumable Parts
WSP-R341 Rev. 1.0 Type : Thermal Paper Paper width : 80mm Paper thickness : 60±5㎛ : Ø40mm or less Outer diameter Recording side : Outside of roll Cautions 1. Do not paste the paper to the core, and the roll paper which has near end mark printing on its near end is recommended. -
Page 27: Revision History
WSP-R341 Rev. 1.0 Date Version Comments Nov. 02. 2015 Initialize http://www.woosim.com...
