Quick Guide
The Start-up Wizard for compressor functions
28-00 Short Cycle Protection
1
[1] Enabled
28-01 Interval between Starts
2
300 s
28-02 Minimum Run Time
3
60 s
28-10 Oil Return Management
4
[1] On
28-11 Low Speed Running Time
5
20 min
28-13 Boost Duration
6
60 s
Figure 1.16 Compressor Function Wizard
Compressor function wizard
Parameter
28-00 Short Cycle Protection
28-01 Interval between Starts
28-02 Minimum Run Time
28-10 Oil Return Management
28-11 Low Speed Running Time
28-13 Boost Duration
Table 1.14 Compressor Function
MG18M122
Quick Guide
Option
[0] Disabled
[1] Enabled
0–3600 s
10–3600 s
[0] Off
[1] On
1–1400 min
10–3600 s
Danfoss A/S © Rev. 08/2014 All rights reserved.
Default Function
[1] Enabled Select if short cycle protection is to be used.
300 s Enter the minimum allowed time between
starts.
60 s Enter the minimum allowed time to run
before stop.
[1] On Select if Oil Return Management is to be used.
20 min Enter the low speed running time.
60 s Enter the boost duration for the oil return.
