- Page 1 T811-CM Access Point Installation Guide Applies to 901-T811-US01 Part Number 800-71436-001 Rev A Published July 2017 www.ruckuswireless.com...
- Page 2 TT811-CM AP Installation Guide, 800-71436-001 Rev A...
- Page 3 CONTRACT OR TORT, ARISING FROM YOUR ACCESS TO, OR USE OF, THE MATERIAL. Trademarks Ruckus Wireless, Ruckus, Bark Logo, and ZoneFlex are trademarks of Ruckus Wireless, Inc. in the United States and other countries. All other product or company names may be trademarks of their respective owners.
-
Page 4: T811-Cm Ap Installation Guide, 800-71436-001 Rev A
TT811-CM AP Installation Guide, 800-71436-001 Rev A... -
Page 5: Table Of Contents
Installing the Cable Power Tap ........................23 Powering the T811-CM with POC ......................24 Checking the T811-CM Signal Level with an RF Power Meter (Optional) ............ 25 Configuring the T811-CM for the First Time (Optional) ................26 Re-Installing an Access Plug or Hardline Adapter..................35 Verifying CM and AP Operation ........................ - Page 6 Appendix C: Replacing the F Connector Adapter Appendix D: Rebooting and Resetting the T811-CM Rebooting and Resetting the AP and CM ..................... 51 Using the Reset Button Inside the AP ......................51 Remotely Rebooting and Factory Resetting the AP ..................52 Rebooting and Factory-Resetting the CM ....................
-
Page 7: About This Installation Guide
About This Installation Guide This Installation Guide provides information on how to set up the Ruckus Wireless T811-CM (model 901-T811-CM-US31) strand mount access point (AP) with integrated cable modem (CM) on your network. Topics covered in this guide include basic configuration, operation and mounting. The rest of this document refers to the strand mount access point with integrated cable modem as the T811-CM. -
Page 8: Using This Installation Guide
About This Installation Guide Using this Installation Guide Using this Installation Guide The T811-CM installation is completed with four main steps. Each step includes some substeps. Figure 2 shows the main steps, and Table 1 includes the substeps. Figure 2. Adding a T811-CM to an existing Ruckus Wireless network flowchart... - Page 9 About This Installation Guide Using this Installation Guide Table 1. Adding a T811-CM to an Existing Ruckus Wireless network Section Heading Planning the T811-CM Installation • T811-CM Omni Antenna Coverage • Powering Options • Performing a Site Survey Installing the T811-CM •...
-
Page 10: Terms Used In This Guide
Terms Used in This Guide Before continuing, Ruckus Wireless recommends that you become familiar with the following terms: • T811-CM: T811-CM strand mount AP with integrated CM, which includes the AP and CM and the cable strand interface. • AP: The Wi-Fi Access Point part of the T811-CM. -
Page 11: Planning The T811-Cm Installation
Planning the T811-CM Installation Before installing the T811-CM, plan the T811-CM installation. In this chapter: • T811-CM Omni Antenna Coverage • Powering Options • Performing a Site Survey T811-CM AP Installation Guide, 800-71436-001 Rev A... -
Page 12: T811-Cm Omni Antenna Coverage
APs in a connecting device. See Figure 3 for internal-antenna coverage patterns, and see Figure 4 for a typical mesh coverage pattern between a T811-CM root AP and a 7782 non-root AP. Figure 3. Omni 5GHz and 2.4GHz coverage Cable Cable Strand... -
Page 13: Powering Options
Planning the T811-CM Installation Powering Options Powering Options The T811-CM supports AC power over cable (POC). 60 to 90 VAC POC is used when the T811-CM is powered via an F-type coaxial cable connected to the HFC cable plant. Performing a Site Survey Perform a site survey to determine the optimal T811-CM placement for maximum range, coverage, and network performance. - Page 14 GPS module can obtain lock and provide accurate GPS time and position. If the GPS antenna has less than a clear 360-degree view of the sky, then the GPS module may experience degraded performance. Fig. 5 T811-CM mounting GPS considerations T811-CM AP Installation Guide, 800-71436-001 Rev A...
- Page 15 Planning the T811-CM Installation Performing a Site Survey T811-CM AP Installation Guide, 800-71436-001 Rev A...
-
Page 16: Installing The T811-Cm
Installing the T811-CM Before installing the T811-CM, Ruckus Wireless recommends that you first complete the procedures described in Planning the T811-CM Installation. In this chapter: • Safety Information • Unpacking the T811-CM • AP and CM MAC Addresses, Connectors and Ground Point •... - Page 17 AP installation must comply with local regulatory requirements, especially with those regulating operation near military and/or weather radar systems. WARNING! Installation of this equipment must comply with local and national electrical codes. Ruckus Wireless strongly recommends that you wear eye protection before mounting WARNING! the AP. CAUTION! Make sure that you form a 80mm - 130mm (3”-5”) drip loop in any cable that is attached...
-
Page 18: Unpacking The T811-Cm
Package Contents A Ruckus Wireless T811-CM package contains the items listed below: • Ruckus Wireless T811-CM unit with cable strand hangers, includes one 12mm long stainless steel M6x1 earth ground panhead screw with split lock and flat washers • A one-meter green/yellow earth ground wire with ring terminal •... -
Page 19: Ap And Cm Mac Addresses, Connectors And Ground Point
AP and CM MAC Addresses, Connectors and Ground Point AP and CM MAC Addresses, Connectors and Ground Point The T811-CM MAC address label lists separate addresses for the internal AP and the cable modem (CM). The MAC address label (1 in Figure... -
Page 20: Leds And Reset Button/Diagnostic Ethernet Port
LEDs on the T811-CM, and Table 3 describes the LEDs and the reset button/diagnostic Ethernet port. Figure 6. T811-CM LEDs and reset button/diagnostic Ethernet port when the dome is pointing downwards Table 3. LEDs and reset button/diagnostic Ethernet port No. Label... - Page 21 • Supports the following SFP modules: • Finisar GPON FTGN2117P2TUN • Finisar EPON FTEN2217P1CUN-BC • Finisar 1000BaseLX FLTF1318P3BLT • Xavi XO-3901 GPON ONT (***XXX*** need to verify) • (***XXX*** add SFP LED behavior) T811-CM AP Installation Guide, 800-71436-001 Rev A...
-
Page 22: Led Startup Sequence
The AIR LED indicates Mesh AP upstream connectivity; therefore it will not generally be lit on a cable modem AP, whose backhaul should be the cable modem rather than a mesh link. LED Startup Sequence (SFP Backhaul) (***XXX***) T811-CM AP Installation Guide, 800-71436-001 Rev A... -
Page 23: Deploying The T811-Cm
Configuring the T811-CM for the First Time (Optional) Mounting the T811-CM To mount the T811-CM assembly on a cable strand, you need to secure the cable clamps that are attached to the strand interface to the cable strand. 1 Slightly loosen the nuts that fasten the two cable clamps to the strand interface, enough for the strand support cable to fit into the cable clamps. -
Page 24: Earth Grounding The T811-Cm
Earth Grounding the T811-CM The cable strand is usually earth-grounded, and mounting the T811-CM on the cable strand earth grounds the T811-CM chassis as well; if this is the case, skip this procedure and continue with Installing the Cable Power Tap. -
Page 25: Installing The Cable Power Tap
The CATV coaxial cable used in the field deployment must have 60 to 90 VAC power multiplexed with the RF signal on the coaxial cable, since the T811-CM Connector B is used for both electrical power and the RF signal. -
Page 26: Powering The T811-Cm With Poc
Deploying the T811-CM Powering the T811-CM with POC 60 to 90 VAC POC is used when the T811-CM is mounted on a cable strand and powered via an F- type coaxial cable connected to the HFC cable plant. 1 Remove the power jumper from the power tap to remove AC power out of the power tap. -
Page 27: Checking The T811-Cm Signal Level With An Rf Power Meter (Optional)
Installing the T811-CM Deploying the T811-CM Checking the T811-CM Signal Level with an RF Power Meter (Optional) The CMAP cable modem is just like a standard DOCSIS 3.1 modem installed at home. Connect an RF power meter to the cable from the cable power tap to measure the downstream power coming from the cable. -
Page 28: Configuring The T811-Cm For The First Time (Optional)
Access Plug or Hardline Adapter. (***XXX*** add SFP use case) If the T811-CM AP and CM do not receive their latest firmware downloads and initial configurations from the CMTS equipment when the T811-CM powers up, then continue with this procedure: •... - Page 29 Operating the Operating the CM In addition to the T811-CM AP command line interface (CLI) and Web interface, the CM part of the T811-CM also has Web and CLI interfaces. With these interfaces, you can operate the CM part. Refer to the following sections: NOTE The cable modem and access point each has its own independent firmware load that is updated independently.
- Page 30 (see Figure 3 Connect one end of an Ethernet cable to the Ethernet port on the T811-CM, and then connect the other end to the administrative computer’s Ethernet port. 4 On the administrative computer, open a Web browser window.
- Page 31 2 Click Connection in the left sidebar. The CM Web interface displays the Connection Status page. NOTE The Downstream Power indicated in the Power column is accurate to +/-3dB. Figure 10. Connection Status page - Page 1 of 2 T811-CM AP Installation Guide, 800-71436-001 Rev A...
- Page 32 1 Log into to the Status page as described in Logging Into the CM Web Interface. 2 Click Security in the left sidebar. The CM Web interface displays the Security Status page. T811-CM AP Installation Guide, 800-71436-001 Rev A...
- Page 33 Deploying the T811-CM Figure 13. Security Status page 3 Ruckus Wireless recommends that you change the login and/or password as follows: a Enter a new CM user ID in Password Change User ID. b Enter a new CM user password in New Password.
-
Page 34: Re-Installing An Access Plug Or Hardline Adapter
• Torque wrench and/or torque screwdriver with sockets and bits • 100% silicon sealant 2 If you have connected an administrative computer to the Ethernet cable to the T811-CM Ethernet port, then disconnect the cable. 3 Wipe any dirt or other contaminants off the access plug or stinger O-ring, and the O-ring mating surface. -
Page 35: Operating And Troubleshooting The T811-Cm
AP MAC addresses are printed on labels on the outside of the T811-CM, as described in and CM MAC Addresses, Connectors and Ground Point. If you cannot find the CM’s MAC address on the T811-CM, you can retrieve it via the CMTS using the AP and CM command line interfaces: •... -
Page 36: Rebooting And Resetting The T811-Cm
Operating and Troubleshooting the T811-CM Rebooting and Resetting the T811-CM 2 Connect an administrative computer to the same subnet as the T811-CM. 3 On the administrative computer, start the Telnet or SSH (secure shell) client program. 4 Log onto to the AP using Telnet or SSH with the following logon details: •... -
Page 37: How Radio Frequency Scanning Works
NOTE The scanning of generic DOCSIS channels is required the first time the T811-CM connects to an MSO. After the initial scan, the T811-CM is able to retrieve the local country frequency plan without a complete scan during its normal operation. - Page 38 Operating and Troubleshooting the T811-CM How Radio Frequency Scanning Works T811-CM AP Installation Guide, 800-71436-001 Rev A...
-
Page 39: What To Do Next
What to Do Next The following are some of the post-installation tasks that Ruckus Wireless recommends. Refer to the Ruckus Wireless Outdoor Access Point User Guide for more information on configuring and managing the AP. Changing the Administrative Password Management access to the Web interface of the AP is controlled through administrative user name and password. - Page 40 What to Do Next Reading Related Documentation T811-CM AP Installation Guide, 800-71436-001 Rev A...
-
Page 41: Appendix A: Ruckus Wireless Factory- And Customer-Supplied Parts
Factory-supplied and customer-supplied parts Part Ruckus T811-CM Notes Wireless P/N Kit or Customer li d 1m lugged earth T811-CM kit ground wire Cable power tap Customer Antronix and connecting supplied MGT2000-SDPE cable tap, or equivalent T811-CM AP Installation Guide, 800-71436-001 Rev A... - Page 42 T811-CM AP Installation Guide, 800-71436-001 Rev A...
-
Page 43: Appendix B: T811-Cm Mounting Dimensions And Weight
Appendix B: T811-CM Mounting Dimensions and Weight Dimensions Figure 14. T811-CM length--all dimensions in millimeters and [inches] (***XXX*** need new drawings) T811-CM AP Installation Guide, 800-71436-001 Rev A... - Page 44 Dimensions Figure 15. T811-CM height and width--all dimensions in millimeters and [inches] (***XXX*** need new drawings) T811-CM AP Installation Guide, 800-71436-001 Rev A...
-
Page 45: Weight
Weight Weight The T811-CM weighs 9.5 pounds. For other specifications, refer to the Ruckus Wireless data sheet. (***XXX*** need new weight specs.) T811-CM AP Installation Guide, 800-71436-001 Rev A... - Page 46 Weight T811-CM AP Installation Guide, 800-71436-001 Rev A...
-
Page 47: Appendix C: Replacing The F Connector Adapter
3 Using a No. 2 Phillips screwdriver, loosen the Phillips retaining screw holding down the existing stinger pin only enough to release the stinger pin. DO NOT remove the Phillips retaining screw, or it could fall down into the chassis of the T811-CM. 4 Using the 3/4” wrench, unscrew and remove the stinger (2 in Figure 16). - Page 48 10 Using a torque screwdriver or wrench, tighten the stinger access plug (1 in Figure 16) to 1.7N.m or 15in-lbs as described in Re-Installing an Access Plug or Hardline Adapter. You have completed replacing the stinger/hardline adapter. T811-CM AP Installation Guide, 800-71436-001 Rev A...
-
Page 49: Appendix D: Rebooting And Resetting The T811-Cm
Also note that resetting and/or rebooting the AP and CM disrupts all wireless network communications through this device. There are different ways to reboot or reset the AP and CM parts of the T811-CM: • Using the Reset Button Inside the AP •... -
Page 50: Remotely Rebooting And Factory Resetting The Ap
2 Start your MIB browser. 3 Load the Ruckus Wireless MIBs onto the MIB browser. 4 In the MIB browser, specify the IP address of the T811-CM AP. (You can obtain this information from the DHCP server on the network.) 5 Find the OID 1.3.6.1.4.1.25053.3.1.4.7.3 (ruckusZF7761CMControlLED). -
Page 51: Rebooting And Factory-Resetting The Cm
2 Start your MIB browser. 3 Load the Ruckus Wireless MIBs onto the MIB browser. 4 In the MIB browser, specify the IP address of the T811-CM access point or cable modem. (You can obtain this information from the DHCP server on the network.) 5 Find the OID 1.3.6.1.4.1.25053.3.1.4.7.3 (ruckusZF7761CMControlLED). - Page 52 T811-CM AP Installation Guide, 800-71436-001 Rev A...
- Page 53 T811-CM AP Installation Guide, 800-71436-001 Rev A...
- Page 54 Copyright © 2006-2017. Ruckus Wireless, Inc. 350 West Java Dr. Sunnyvale, CA 94089. USA www.ruckuswireless.com...
