Ruckus Wireless
™
ZoneFlex
7761CM Dual Band 802.11n
Outdoor Access Point
with Integrated Cable Modem

Installation Guide

Part Number 800-70290-001
Published May 2010
www.ruckuswireless.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZoneFlex 7761-CM and is the answer not in the manual?

Questions and answers

Related Manuals for Ruckus Wireless ZoneFlex 7761-CM

Summary of Contents for Ruckus Wireless ZoneFlex 7761-CM

  • Page 1: Installation Guide

    ™ Ruckus Wireless ™ ZoneFlex 7761CM Dual Band 802.11n Outdoor Access Point with Integrated Cable Modem Installation Guide Part Number 800-70290-001 Published May 2010 www.ruckuswireless.com...

  • Page 3: Table Of Contents

    Contents About This Installation Guide ..........1 Related Documentation .
  • Page 4 Contacting Ruckus Wireless Support ........

  • Page 5: About This Installation Guide

    Web interface. Using ZoneDirector to Manage the CMAP If you are planning to use a Ruckus Wireless ZoneDirector to manage the CMAP, this guide describes the required steps that will enable the access point to report to and communicate with ZoneDirector successfully.

  • Page 6: Terms Used In This Guide

    Unpacking the CMAP Terms Used in This Guide Terms Used in This Guide Before continuing, Ruckus Wireless recommends that you become familiar with the following terms: Access Point (AP): The Wi-Fi component of the Cable Modem Access Point (CMAP). ■...
  • Page 7 Unpacking the CMAP Package Contents Figure 1. The CMAP comes preassembled with the cable strand interface Cable Strand Interface Access Point...

  • Page 8: Preparing For Installation

    Wireless ZoneDirector or Ruckus Wireless FlexMaster. Preconfiguring the Access Point (Standalone Only) If you are deploying the access point as a standalone device, Ruckus Wireless strongly recommends that you preconfigure (or “stage”) the unit before mounting it. It is more convenient to connect the administrative computer to the access point and configure the device in the lab than when the device is already mounted on the cable strand.

  • Page 9: Step 1: Prepare The Administrative Computer

    Preparing for Installation Preconfiguring the Access Point (Standalone Only) Step 1: Prepare the Administrative Computer NOTE: The following procedures are applicable if the administrative computer is running on Windows XP. If you are using a different operating system, refer to the documentation that was shipped with your operating system for information on how to modify the computer’s IP address settings.
  • Page 10 Preparing for Installation Preconfiguring the Access Point (Standalone Only) Figure 2. Sample configuration in the Internet Protocol Version 4 (TCP/IPv4) Properties dialog box On Microsoft Windows XP 1. Click Start > Control Panel > Network Connections. 2. When the Network Connections window appears, right-click the icon for Local Area Connection, and then click Properties.
  • Page 11 Preparing for Installation Preconfiguring the Access Point (Standalone Only) 5. Click Use the following IP address, and then configure the IP address settings with the values listed in Table 2. For a sample configuration, refer to Figure Table 2. Configure your computer’s IP address settings IP address 192.168.100.77 (or any address on the 192.168.100.x network —...

  • Page 12: Step 2: Supply Power To The Cmap

    Preparing for Installation Preconfiguring the Access Point (Standalone Only) Step 2: Supply Power to the CMAP In this step, you will connect the CMAP to the administrative computer, and then you will power it on using 12 VDC power. NOTE: Before starting this procedure, you must have already obtained a DC power supply, such as 705-60224-002 shown in Figure To supply DC power to the CMAP...

  • Page 13: Step 3: Log Into The Access Point's Web Interface

    Preparing for Installation Preconfiguring the Access Point (Standalone Only) Table 3. DC switching adapter components Number Description Connector for the 12VDC connector on the CMAP Reset switch Step 3: Log Into the Access Point’s Web Interface 1. On the administrative computer, open a Web browser window. 2.

  • Page 14: Step 4: Configure The Wireless Settings

    Preparing for Installation Preconfiguring the Access Point (Standalone Only) Step 4: Configure the Wireless Settings To complete this step, you will need to configure the settings on the Common tab and at least one Wireless # tab. These are the essential wireless settings that will enable wireless devices on the network to associate with the access point.
  • Page 15 Preparing for Installation Preconfiguring the Access Point (Standalone Only) Table 5. Common wireless configuration Setting Recommended Value Country Code • If you purchased the access point in the United States, this value is fixed to United States at the factory and is not user-configurable.
  • Page 16 4. Clear the SSID box, and then type a unique and descriptive name that you want to call this wireless network. For example, you can type Ruckus Wireless AP. This SSID is the name that will help users identify this wireless network in their wireless network connection application.
  • Page 17 Preparing for Installation Preconfiguring the Access Point (Standalone Only) Figure 8. Type the FlexMaster server URL...

  • Page 18: Step 5: Disconnect The Cmap From The Administrative Computer

    Preparing for Installation Pointing the CMAP to ZoneDirector Step 5: Disconnect the CMAP from the Administrative Computer 1. Disconnect the CMAP from the DC power source. 2. Verify that all LEDs are off. 3. Disconnect the Ethernet cable from the administrative computer’s Ethernet port. Step 6: Restore the Administrative Computer’s Network Settings 1.

  • Page 19: Use Ssh To Set The Zonedirector Ip Address On The Cmap

    Preparing for Installation Pointing the CMAP to ZoneDirector Use SSH to Set the ZoneDirector IP Address on the CMAP You can use SSH to set the IP address of the ZoneDirector device that you want to use to manage the CMAP. Before starting this procedure, you must obtain the IP address of the ZoneDirector device to which you want to assign the CMAP.

  • Page 20: Configure Option 43 On The Dhcp Server (Zonedirector Management Only)

    Preparing for Installation Pointing the CMAP to ZoneDirector Configure Option 43 on the DHCP Server (ZoneDirector Management Only) You can configure the DHCP server on your CMTS backbone to ensure that the CMAP will successfully discover its parent ZoneDirector on the network. To customize your DHCP server, you need to configure DHCP Option 43 (043 Vendor Specific Info) with the IP address of the ZoneDirector device on the network.
  • Page 21 Preparing for Installation Pointing the CMAP to ZoneDirector Figure 9. In the ASCII area, type the IP address of the ZoneDirector device The hexadecimal equivalent of the ZoneDirector IP address appears in the Binary text area. NOTE: If there are multiple ZoneDirector devices on the network, type all the IP addresses in the ASCII text area.
  • Page 22 Preparing for Installation Pointing the CMAP to ZoneDirector If Only ZoneDirector Exists on the Network (With ZoneDirector Subcode) 1. From Control Panel > Windows Administrative Tools, open DHCP, and then select the DHCP server you want to configure. 2. If the Scope folder is collapsed, click the plus (+) sign to expand it. 3.
  • Page 23 Preparing for Installation Pointing the CMAP to ZoneDirector 7. After the ZoneDirector subcode (03), type the hexadecimal equivalent of the length of the ZoneDirector IP address. For example, if the ZoneDirector IP address is 192.168.10.1, the length in decimal is 12 and the hexadecimal equivalent is 0B. Figure 11.
  • Page 24 Preparing for Installation Pointing the CMAP to ZoneDirector Figure 12. In the ASCII text area, type the ZoneDirector IP address 9. Click Apply to save your changes. 10. Click OK to close the Scope Options dialog box. You have completed configuring DHCP Option 43 to provide supported APs with the ZoneDirector IP address.
  • Page 25 Preparing for Installation Pointing the CMAP to ZoneDirector The table below lists the FlexMaster URL and ZoneDirector IP address that are used as examples in this procedure, including their length in decimal and hexadecimal values. Table 6. URL/IP address values that are used as examples in this procedure URL / IP Address Decimal Length Hexadecimal Length FlexMaster...
  • Page 26 Preparing for Installation Pointing the CMAP to ZoneDirector Figure 13. Type 01, the subcode for FlexMaster 7. Under the Binary text area, position the cursor after the 01 subcode, and then type 21 – the hexadecimal equivalent of the FlexMaster server URL length that is used as the example in this procedure.
  • Page 27 Preparing for Installation Pointing the CMAP to ZoneDirector Figure 14. After the 01 subcode for FlexMaster, type 21 – the hexadecimal equivalent of the FlexMaster server URL length 8. Position the cursor under the ASCII text area, and then type the FlexMaster server URL. In the example below, the FlexMaster server URL is http://192.168.10.1/intune/server.
  • Page 28 Preparing for Installation Pointing the CMAP to ZoneDirector Figure 15. In the ASCII text area, type the FlexMaster server URL 9. Position your cursor again after the last octet (in this example, 72) under the Binary text area, and then type 03 (the subcode for ZoneDirector).
  • Page 29 Preparing for Installation Pointing the CMAP to ZoneDirector Figure 16. Under the Binary text area, type 03 (the subcode for ZoneDirector) 10. After the ZoneDirector subcode (03), type the hexadecimal equivalent of the length of the ZoneDirector IP address length. For example, if the ZoneDirector IP address is 192.168.10.2, the length in decimal is 12 and the hexadecimal equivalent is 0C.
  • Page 30 Preparing for Installation Pointing the CMAP to ZoneDirector Figure 17. After the ZoneDirector subcode, type the hexadecimal equivalent of the ZoneDirector IP address length 11. Position the cursor under the ASCII text area after the FlexMaster server URL, and then type the ZoneDirector IP address.
  • Page 31 Preparing for Installation Pointing the CMAP to ZoneDirector Figure 18. In the ASCII text area, type the ZoneDirector IP address (two bytes after the FlexMaster server URL) There should be a two- byte gap between the FlexMaster URL and ZoneDirector IP address 12.

  • Page 32: Hardware Features

    CMAP features that are relevant to the installation and mounting instructions that this guide provides. Before you begin the installation process, Ruckus Wireless recommends that you first become familiar with these features. Figure 19. CMAP parts and connectors (Connector side)
  • Page 33 Hardware Features Pointing the CMAP to ZoneDirector Table 7. Parts and connectors on the CMAP Label Description Ethernet Port RJ45 port that supports 10/100Mbps connections and provides Power over Ethernet (PoE) power to compliant devices. Antenna Connector One of the three connectors for the three 5GHz antennas supplied with the CMAP.

  • Page 34: Weight And Dimensions

    Hardware Features Weight and Dimensions Figure 20. CMAP parts and connectors (LED side) Antenna Connectors LEDs Table 8. LEDs and connectors on the CMAP Label Description Antenna Connectors Two of the three connectors for the 5GHz antennas. The other connector is located on the other side of the unit (see Figure 19).

  • Page 35: Connectors

    Three N-type antenna connectors: Connects to the three 5GHz antennas supplied with ■ the CMAP. DC power supply (Ruckus Wireless part number 705-60244-002): Connected through ■ a 4-pin connector, which is normally unused. It may be used to supply DC power to the unit for testing or configuration purposes.
  • Page 36 Hardware Features LEDs the access point’s MAC address. If you are unable to find the access point, then it is very likely to be in standalone mode. If you have multiple ZoneDirector devices on the network, make sure you check each one of them. Table 9 describes the behavior of the LEDs on the CMAP when it is in CM, AP standalone, and AP ZoneDirector modes.

  • Page 37: Supported Power Sources

    Hardware Features Supported Power Sources Supported Power Sources The CMAP supports the following power sources: Power over Cable (POC): 40 to 90V AC supplied through the RF coaxial cable (attached ■ to Connector B) that is connected to the cable modem termination system (CMTS) backbone.

  • Page 38: Cable Modem Operation

    Cable Modem Operation Logging Into the CM Web Interface Cable Modem Operation The CMAP provides a separate cable modem Web interface that you can use to view the connection and software statuses and to configure basic device security settings. To access the cable modem Web interface, you will need the following: An administrative computer ■...

  • Page 39: Viewing The Software Status

    Cable Modem Operation Viewing the Software Status Viewing the Software Status The Software Status page displays information about the current software version that installed on the cable modem and its system status. Figure 21. Software Status page...
  • Page 40 Cable Modem Operation Viewing the Software Status There are two tables on the Software Status page – Information and Status. Table 10 Table 11 list the information that these tables display. Table 10. Information (software) table Item Description Standard Specification Compliant The standard with which the device is compliant Hardware Version The version of the cable modem hardware Software Version...

  • Page 41: Viewing The Connection Status

    Cable Modem Operation Viewing the Connection Status Viewing the Connection Status The Connection Status page displays information about the cable modem’s Hybrid Fiber Coax (HFC) and IP network connectivity, including its downstream and upstream channels and the IP address that is currently assigned to the cable modem. To access the Connection Status page, click Connection on the menu on the left sidebar.

  • Page 42: Configuring The Downstream Frequency

    Cable Modem Operation Configuring the Downstream Frequency Configuring the Downstream Frequency The Configure page allows you to set the downstream frequency for the cable modem, Configuring the downstream frequency will enable the device to quickly obtain a direct frequency lock with the CMTS upon bootup and help save approximately 40 minutes of scanning for available downstream frequency from the CMTS.

  • Page 43: Before You Begin

    Before You Begin Prepare the Required Hardware and Tools Before You Begin Before installing and setting up the CMAP, Ruckus Wireless recommends that you first complete the following pre-installation tasks. Prepare the Required Hardware and Tools You must supply the following tools and equipment: A notebook computer running Windows 7/Vista/XP with one wireless 802.11b/g/n...
  • Page 44 Before You Begin Perform a Site Survey Power and backhaul connections: Of course, the CMAP needs a backhaul connection ■ to the CMTS and it needs to be close enough to an AC power inserter on the CATV cable to assure that it will be able to pull 60 watts at greater than 45 VAC. If not, then another power inserter must be installed closer to the CMAP.

  • Page 45: Powering The Cmap

    Powering the CMAP Using DC Power (Staging or Debugging Only) Powering the CMAP The CMAP supports both POC (AC) and DC power. Depending on whether you are have access to 45 to 90 VAC on the CMTS CATV cable or would prefer to power it with 120-240 VAC and a 12 VDC adaptor, follow the relevant procedure below.

  • Page 46: Verifying Access Point Operation

    “Step 4: Configure the Wireless Settings” on page 10. For example, if you set the SSID to Ruckus Wireless AP, click the wireless network named Ruckus Wireless AP. If ZoneDirector is managing the access point, the wireless settings would have been included in the configuration file that the access point downloaded when it registered with ZoneDirector.

  • Page 47: Verifying Cable Modem Operation

    Verifying Cable Modem Operation Using Power Over Cable (Actual Deployment) Verifying Cable Modem Operation To verify that the cable modem is operating normally, you will need to log on to the cable modem’s Web interface. 1. Obtain the IP address that is assigned to the cable modem. You can obtain this information from the DHCP server at the CMTS.

  • Page 48: Switching Leds To Cable Modem Mode

    Switching LEDs to Cable Modem Mode Using the AP’s Web Interface to Switch to CM Mode Switching LEDs to Cable Modem Mode The LEDs indicate the statuses of both the access point and cable modem components. However, they can only show the status of one or the other at a time – either access point status only (AP Mode) or cable modem status only (CM Mode).

  • Page 49: Using Snmp To Switch To Cm Mode

    Use SNMP to set MIB values on the CMAP that control the LED mode. NOTE: Before starting this procedure, you must first obtain the related MIBs from Ruckus Wireless. Contact your authorized Ruckus Wireless sales representative or Ruckus Wireless Support. Visit http://support.ruckuswireless.com/contacts for contact information.

  • Page 50: Resetting The Access Point To Factory Default Settings

    Resetting the Access Point to Factory Default Settings Using the Reset Switch on the DC Power Supply You have completed switching the LEDs to CM Mode using SNMP. Resetting the Access Point to Factory Default Settings There are two ways to reset the access point to factory default settings: Using the Reset Switch on the DC Power Supply ■...

  • Page 51: Using Snmp To Reset The Access Point

    The IP address that is assigned to the access point that you want to reset to factory ■ default settings. You can obtain this information from the DHCP server on the network. Obtain the related MIBs from Ruckus Wireless. Contact your authorized Ruckus ■ Wireless sales representative or Ruckus Wireless Support. For the Ruckus Wireless Support contact information, visit the following Web address: http://support.ruckuswireless.com/contacts...
  • Page 52 Resetting the Access Point to Factory Default Settings Using SNMP to Reset the Access Point 4. In the MIB browser, specify the IP address of the access point that you want to reset to factory default settings. 5. Find the OID 1.3.6.1.4.1.25053.3.1.4.7.3 (ruckusZF7761CMControlLED). 6.

  • Page 53: Resetting The Cm To Factory Default Settings

    The IP address that is assigned to the access point that you want to reset to factory ■ default settings. You can obtain this information from the DHCP server on the network. Obtain the related MIBs from Ruckus Wireless. Contact your authorized Ruckus ■ Wireless sales representative or Ruckus Wireless Support. For the Ruckus Wireless Support contact information, visit the following Web address: http://support.ruckuswireless.com/contacts...

  • Page 54: Mounting The Cmap

    Mounting the CMAP Using SNMP to Reset the Access Point Mounting the CMAP To mount the CMAP assembly on a cable strand, you need to secure the cable clamps that are attached to the strand interface bracket to the cable strand. NOTE: The CMAP must be installed on a cable strand by a professional cable installer.

  • Page 55: Installing The Antennas

    After you mount the CMAP on the cable strand, the next step is to install the three 5GHz antennas that are supplied with the CMAP. To avoid damaging the antennas, Ruckus Wireless strongly recommends that CAUTION: you install the antennas only after you mount the CMAP on the cable strand and have attached the strand coaxial cable to Connector B.

  • Page 56: What To Do Next

    Change the Administrative Password What to Do Next The following are some of the post-installation tasks that Ruckus Wireless recommends. Refer to the ZoneFlex 7761CM Dual Band 802.11n Outdoor Access Point with Integrated Cable Modem User Guide for more information on configuring and managing the access point.

  • Page 57: How Radio Frequency Scanning Works

    Troubleshooting How Radio Frequency Scanning Works An Ethernet cable ■ A Telnet or SSH (secure shell) client program ■ Do the following 1. Connect one end of the Ethernet cable to the administrative computer’s Ethernet port, and then connect the other end to the CMAP’s Ethernet port. 2.

  • Page 58: Eurodocsis-Compliant Cmap

    MSO. After the initial scan, the CMAP will be able to retrieve the local country frequency plan during its normal operation. Contacting Ruckus Wireless Support For assistance in troubleshooting other issues that are not described in this guide, contact Ruckus Wireless technical support (see below): Email: support@ruckuswireless.com ■ Web Site: http://support.ruckuswireless.com/ ■...
