1.3. DELIVERY SET

Delivery set of ACB-09E includes the following:
Cotton candy machine
Plastic pan
'No-Snow' tool
Silicone sealing collar
Silicone adjustment ring
Power supply cord
Operation manual
PLASTIC PAN IS AN INTEGRAL PART OF THE MACHINE. IT IS
IMPOSSIBLE TO OPERATE THE EQUIPMENT WITHOUT THIS
PART!
Plastic pan dimensions are 680x680x240 mm, net weight 2 kg.
1.4. MACHINE DESIGN AND OPERATION PRINCIPLE
Cotton candy machine has the following main parts: Housing (1); Chassis
(2) with electric motor; Spinning Head (3). Spinning head with electric
motor is rigidly mounted on the chassis that placed on spring-loaded
supports that based on the housing. The supports soften vibrations that
arise while motor in operation. Plastic pan (18) is not shown.
COTTON CANDY MACHINE ACB-09E REVISED 28-Sep-17
1 pc.
1 pc.
1 pc.
1 pc.
2 pc.
1 pc.
1 copy
