1. OVERVIEW AND OPERATION

1.1. DESIGNATION
ACB-09E is intended for cotton candy producing, using granulated sugar
with different complex food additives. Due to unique and patented design,
the equipment allows operation under high ambient temperature and
excessive relative humidity. Candy floss leaves the machine upwards,
allowing making cotton servings unlimited huge, up to 2(!) meters in
diameter. After some practice, operator can step 5 meter away from the
machine and keep making sweet cotton!

1.2. TECHNICAL SPECIFICATIONS

Model
'Cold start' time
Productivity
Spinning rate
Rated power
Rated voltage
Dimensions (machine only)
Dimensions (pan included)
Weight
The equipment must be operated at the ambient temperature from +5° to
+40°C and relative humidity not more than 50% at 40°C. The temperature
decreasing related to RH increasing, for example, 90% of RH at 20°C.
Altitude above sea level should not exceed 1000 m.
Ingress protection rating IP20 (IEC 60529).
ACB-09E machine is made in accordance to the following requirements:
TR CU 010/2011 On the safety of machinery and equipment
ТR СU 004/2011 On safety of low voltage equipment
TR CU 020/2011 Electromagnetic compatibility of technical equipment
And also in accordance with the following directives:
2006/42/ЕС Machinery Directive
2014/35/EU Low Voltage Directive
2014/30/EU EMC Directive
COTTON CANDY MACHINE ACB-09E
RoboJetFloss
60 s
not more than 1450 W
REVISED 28-Sep-17
RoboJetFloss Pro
up to 5 kg/h
up to 2950 rpm
230V 50/60Hz
370x400x370 mm
670x670x480 mm
not more than 15 kg
20 s
3
