I/O Connectors

2.5.1 Connectors, Cables – Main I/O Connector
Table 2-1 lists the board connectors, applicable cables and compatible accessory boards.
Table 2-1. Board Connectors, Cables, Accessory Equipment
Connector type
Compatible Cables
Compatible accessory products
(with C100HD50-xx cable)
Compatible accessory products
(with C100MMS-x cable)
Shielded SCSI 100 D-Type
C100HD50-x, unshielded ribbon cable; x = 3
or 6 feet
C100MMS-x, shielded round cable; x = 1, 2
or 3 meters
ISO-RACK16/P
ISO-DA02/P (PCI-DAS6035 only)
BNC-16SE
BNC-16DI
CIO-MINI50
CIO-TERM100
SCB-50
SCB-100
