Noise Performance
Table 4 below summarizes the noise performance for the PCI-DAS6035/6034. Noise
distribution is determined by gathering 50K samples with inputs tied to ground at the user
connector. Samples are gathered at the maximum specified single-channel-sampling rate.
Specification applies to both single-ended and differential modes of operation.
Table 4 – Analog Input Noise Performance
Range
±10V
±5V
±500mV
±50mV
Analog Output Section (PCI-DAS6035 only)
D/A Converter type
Resolution
Number of Channels
Voltage Range
Monotonicity
DNL
Slew Rate
Settling Time (full scale step)
Noise
Glitch Energy
Current Drive
Output short-circuit duration
Output coupling
Output impedance
Power up and reset
Table 5 – Analog Output Absolute Accuracy
Range
±10V ±1.7 LSB
Table 6 – Absolute Accuracy Components
Range % of Reading
±10V ±0.0219
Each PCI-DAS6035 is tested at the factory to assure the board's overall error does not
exceed ±1.7 LSB.
Typical Counts
Double-buffered, multiplying
12-bits, 1 in 4096
2 voltage output
±10V
12-bits, guaranteed monotonic
±1 LSB max
10V/µs min
10 µs to ±0.5 LSB accuracy
200µVrms, DC to 1MHz BW
24mV @ 2µS duration, measured at mid-scale transition.
±5 mA
Indefinite @ 25mA
DC
0.1 ohms max
DACs cleared to 0 volts ±200mV max
Absolute Accuracy
Offset (mV) Temp Drift (%/ ºC)
±5.93 ±0.0005
6–4
7
7
11
45
Absolute Accuracy at FS (mV)
±8.127
Specifications
LSB rms
0.7
0.7
1.1
5.6
