PCI-DAS6034 & PCI-DAS6035 User's Guide
Digital Input / Output
Digital Type
Number of I/O
Configuration
Input high voltage
Input low voltage
Output high voltage (IOH = –32mA)
Output low voltage (IOL = 32mA)
Data Transfer
Power-up / reset state
Interrupt Section
Interrupts
Interrupt enable
ADC Interrupt sources
(Software Programmable)
DAC Interrupt sources
(Software Programmable)
Discrete, 5V/TTL compatible
8
8 bits, independently programmable for input or output. All
pins pulled up to +5V via 47K resistors (default). Positions
available for pull down to ground.. Hardware selectable
via solder gap.
2.0V min, 7.0V absolute max
0.8V max, –0.5V absolute min
3.80V min, 4.20V typ
0.55V max, 0.22V typ
Programmed I/O
Input mode (high impedance)
PCI INTA# - mapped to IRQn via PCI BIOS at boot-time
Programmable through PLX9080
DAQ_ACTIVE: Interrupt is generated when a DAQ sequence is
active.
DAQ_STOP: Interrupt is generated when A/D Stop Trigger In is
detected.
DAQ_DONE: Interrupt is generated when a DAQ sequence
completes.
DAQ_FIFO_1/4_FULL: Interrupt is generated when ADC FIFO is
¼ full.
DAQ_SINGLE: Interrupt is generated after each conversion
completes.
DAQ_EOSCAN: Interrupt is generated after the last channel is
converted in multi-channel scans.
DAQ_EOSEQ: Interrupt is generated after each interval delay
during multi-channel scans.
DAC_ACTIVE: Interrupt is generated when DAC waveform
circuitry is active.
DAC_DONE: Interrupt is generated when a DAC sequence
completes.
DAC_FIFO_1/4_EMPTY: Interrupt is generated DAC FIFO is ¼
empty.
DAC_HIGH_CHANNEL: Interrupt is generated when the DAC
high channel output is updated.
6–6
Specifications
