PCI-DAS6034 & PCI-DAS6035 User's Guide
DAQ-Sync inter-board Triggers/Clocks
The DAQ-Sync bus provides inter-board triggering and synchronization capability. Five
trigger/strobe I/O pins and one clock I/O pin are provided on a 14-pin header. The DAQ-
Sync signals use dedicated pins. Only the direction may be set.
DAQ-Sync Signals:
Power Consumption
+5V
+5V available at I/O connector
Environmental
Operating Temperature Range
Storage Temperature Range
Humidity
Mechanical
Card dimensions
DS A/D START TRIGGER
DS A/D STOP TRIGGER
DS A/D CONVERT
DS D/A UPDATE
DS D/A START TRIGGER
SYNC CLK
0.9A typical, 1.1A max. . Does not include power
consumed through the I/O connector.
1A max, protected with a resettable fuse
0 to 55°C
–20 to 70°C
0 to 90%, non-condensing
PCI half-card: 174.4mm(L) x 100.6mm(W) x11.65mm(H)
6–9
Specifications
